Stilpnomelane

(K,Ca,Na)(Fe,Mg,Al)8(Si,Al)12(O,OH)36 · nH2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Stp
Discovered
1827
Also known as
  • Chrysobiotite
  • Minguétit
  • Minguétita
  • +1 more

Where it forms, where it's found

Geological setting

Banded iron formations, blueschist and greenschist facies of metamorphic rocks, metamorphosed massive sulphide deposits.

Type locality
Melchior and Tobias adits
  1. Dolní Údolí
  2. Zlaté Hory
  3. Jeseník District
  4. Olomouc Region
  5. Czech Republic

50.2281°, 17.3562°

455recorded occurrences
Source · OpenStreetMap

Varieties

Physical

Hardness
123456789103 – 4/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Red · brown · black · dark green · dark reddish brown · golden brown
Streak
White, grey
Cleavage
Perfect

Perfect on (001) imperfect (010)

Fracture
Micaceous
Density
2.59 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 40°
Refractive index
1.543 – 1.745
Surface relief
Moderate
Principal indices
nα 1.543 – 1.634 · nβ 1.576 – 1.745 · nγ 1.576 – 1.745
Birefringence
0.033
Pleochroism
Visible

X- bright golden yellow to pale yellow Y= Z= deep reddish brown, to deep green to nearly black

Dispersion
none
UV response
Not fluorescent in UV
Notes

The wide variation in reported optics may be due to ferric-dominant stilpnomelanes being regarded as ordinary stilpnomelanes.

Michel-Lévy diagramhighlighted lineδ = 0.0330
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]330 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation330 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 21.724 Å · b = 21.724 Å · c = 17.740 Å
Cell angles
α = 124.14 ° · β = 95.86 ° · γ = 120 °
Ratio a:b:c
1 : 1.000 : 0.817
Z
6
Morphology

Plates or scales, plumose or radiating groups.

Crystal structure

Chemical composition

Impurities
  • Ti
  • Mn
  • Ca
  • Na

Synonyms

  • Chrysobiotite
  • Minguétit
  • Minguétita
  • Minguetite

In other languages

French
stilpnomélane
German
Stilpnomelan
Spanish
Estilpnomelana
Italian
Stilpnomelano
Japanese
スチルプノメレン
Chinese
複鐵變雲母

Classification

Strunz
10th ed.

9.EG.40

  • 9SilicatesClass
  • 9.EPhyllosilicatesDivision
  • 9.EGDouble nets with 6-membered and larger ringsGroup
  • 9.EG.40StilpnomelaneSpecies
Dana
8th ed.

74.01.01.01

  • 74Phyllosilicates Modulated LayersClass
  • 74.01Modulated Layers with joined islandsType
  • 74.01.01Stilpnomelane groupGroup
  • 74.01.01.01StilpnomelaneSpecies
CIM

16.20.9

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.20Aluminosilicates of Fe, Mg and alkalisGroup
  • 16.20.9StilpnomelaneSpecies

Group, growth & confusion

In the same group
3 members
Commonly confused with
3 minerals

Literature, links & citation

Citations
  1. 1827Glocker, Ernst Friedrich (1827) Beschreibung des Stilpnomelan, eines neuen Schlesischen Fossils [Description of Stilpnomelan, a new Silesian Fossil]. In Beyträge zur Mineralogischen Kenntniss der Sudetenländer Insbesondere Schlesiens. Erstes Heft. Josef Mar und Komp. p.68-74.
  2. 1924Grout, Frank F., Thiel, George A. (1924) Notes on stilpnomelane. American Mineralogist, 9 (11) 228-230
  3. 1937Gruner, John W. (1937) Composition and structure of stilpnomelane. American Mineralogist, 22 (8) 912-925
  4. 1938Hutton, C. Osborne (1938) The stilpnomelane group of minerals. Mineralogical Magazine and Journal of the Mineralogical Society, 25 (163) 172-206 doi:10.1180/minmag.1938.025.163.02 DOI: 10.1180/minmag.1938.025.163.02
  5. 1944Gruner, John W. (1944) The structure of stilpnomelane reexamined. American Mineralogist, 29 (7-8) 291-298
