Stokesite

CaSnSi3O9 · 2H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Sks
Discovered
1899
Also known as
  • Stokesiet

Where it forms, where it's found

Geological setting

On axinite

Type locality
Stamps and Jowl Zawn (Roscommon Cliff)
  1. Cliff outcrops
  2. Botallack
  3. St Just
  4. Cornwall
  5. England
  6. UK

50.1475°, -5.6914°

26recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Colourless · white · light blue
Streak
White
Tenacity
brittle
Cleavage
Perfect

Perfect on (101) imperfect on (100)

Fracture
Conchoidal
Density
3.185 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 69° · 2V calc = 66 – 70°
Refractive index
1.609 – 1.619
Surface relief
Moderate
Principal indices
nα 1.609 · nβ 1.613 · nγ 1.619
Dispersion
r < v moderate
Michel-Lévy diagramhighlighted lineδ = 0.0100
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]100 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation100 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
Pnna
Cell parameters
a = 14.465 Å · b = 11.625 Å · c = 5.235 Å
Ratio a:b:c
1 : 0.804 : 0.362
Z
4
Morphology

Prismatic crystals, spherical and radial fibrous aggregates.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1115.999175.989
41.60%
50SnTinTin1118.710118.710
28.06%
14SiSiliconSilicon328.08584.255
19.92%
20CaCalciumCalcium140.07840.078
9.47%
1HHydrogenHydrogen41.0084.032
0.95%
Total423.064100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Stokesiet

In other languages

German
Stokesit
Spanish
stokesita
Italian
Stokesite

Classification

Strunz
10th ed.

9.DM.05

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DMInosilicates with 6-periodic single chainsGroup
  • 9.DM.05StokesiteSpecies
Dana
8th ed.

65.05.01.01

  • 65Inosilicates Single-width, Unbranched Chains, (w=1)Class
  • 65.05Single-Width Unbranched Chains, W=1 with chains P=6Type
  • 65.05.01— unnamed intermediate level —Group
  • 65.05.01.01StokesiteSpecies
CIM

14.12.3

  • 14Silicates not Containing AluminumClass
  • 14.12Silicates of SnGroup
  • 14.12.3StokesiteSpecies

Literature, links & citation

Citations
  1. 1899Hutchinson, A. (1899) On stokesite—a new mineral from Cornwall. The London, Edinburgh, and Dublin Philosophical Magazine and Journal of Science: 48(294): 480-481.
  2. 1900Hutchinson, A. (1900) On Stokesite, a new mineral containing tin, from Cornwall. Mineralogical Magazine and Journal of the Mineralogical Society, 12 (57) 274-281 doi:10.1180/minmag.1900.012.57.07 DOI: 10.1180/minmag.1900.012.57.07
  3. 1960Gay, P., Rickson, K. O. (1960) X-ray data on stokesite. Mineralogical Magazine and Journal of the Mineralogical Society, 32 (249) 433-435 doi:10.1180/minmag.1960.032.249.02 DOI: 10.1180/minmag.1960.032.249.02
  4. 1961Čech, F. (1961) Occurrence of stokesite in Czechoslovakia. Mineralogical Magazine and Journal of the Mineralogical Society, 32 (252) 673-675 doi:10.1180/minmag.1961.032.252.01 DOI: 10.1180/minmag.1961.032.252.01
  5. 1963Vorma, A. (1963) The crystal structure of stokesite CaSnSi3O9.2H2O. Geologinen Tutkimuslaitos Bulletin de la Commission Géologique de Finlande: 208: 1-48.
