Strassmannite

Al(UO2)(SO4)2F · 16H2O
IMA status
  • Approved
IMA symbol
Sßm
IMA approved
2017
Also known as
  • IMA2017-086
  • Strassmanniet
  • Straßmannite

Where it forms, where it's found

Geological setting

Efflorescent mineral, formed in the humid underground workings of an abandoned mine in a sandstone-hosted uranium deposit.

Type locality
Markey Mine
  1. Red Canyon Mining District
  2. San Juan County
  3. Utah
  4. USA

37.5493°, -110.3021°

6recorded occurrences
Source · OpenStreetMap

Radioactivity

Physical

Hardness
123456789101.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Colour
Light yellow–green
Streak
Nearly white
Tenacity
brittle
Cleavage
Distinct/Good

On (001)

Fracture
Irregular/Uneven
Density
2.20 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 70° · 2V calc = 70.2°
Refractive index
1.477 – 1.489
Surface relief
Low
Principal indices
nα 1.477 · nβ 1.485 · nγ 1.489
Pleochroism
Visible

X = nearly colourless, Y = pale green–yellow, Z = light green–yellow

Dispersion
slight, r>v
Extinction
Y = b, X ∧ c = 20° in the obtuse angle β.
UV response
Bright greenish-blue fluorescence with 405 nm excitation
Notes

Absorption: X < Y < Z.

Michel-Lévy diagramhighlighted lineδ = 0.0120
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]120 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation120 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/c
Cell parameters
a = 11.0187(5) Å · b = 8.3284(3) Å · c = 26.673(2) Å
Cell angles
β = 97.426 °
Ratio a:b:c
1 : 0.756 : 2.421
Type-locality form

Equant crystals to 0.2 mm in irregular aggregates to ∼0.5 mm across.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2615.999415.974
52.23%
92UUraniumUranium1238.029238.029
29.89%
16SSulfurSulfur232.06064.120
8.05%
1HHydrogenHydrogen321.00832.256
4.05%
13AlAluminiumAluminium126.98226.982
3.39%
9FFluorineFluorine118.99818.998
2.39%
Total796.359100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2017-086
  • Strassmanniet
  • Straßmannite

In other languages

German
IMA 2017-086 · Strassmannit

Classification

Strunz
10th ed.

7.EB.15

  • 7SulfatesClass
  • 7.EUranyl sulfatesDivision
  • 7.EBWith medium-sized cationsGroup
  • 7.EB.15StrassmanniteSpecies

Literature, links & citation

Citations
  1. 2018Hålenius, U., Hatert, F., Pasero, M., Mills, S. J. (2018) IMA Commission on New Minerals, Nomenclature and Classification (CNMNC) Newsletter 41. European Journal of Mineralogy, 30. 183-186 doi:10.1127/ejm/2018/0030-2736DOI: 10.1127/ejm/2018/0030-2736
  2. 2019Kampf, Anthony R., Plášil, Jakub, Kasatkin, Anatoly V., Nash, Barbara P., Marty, Joe (2019) Magnesioleydetite and straβmannite, two new uranyl sulfate minerals with sheet structures from Red Canyon, Utah. Mineralogical Magazine, 83 (3) 349-360 doi:10.1180/mgm.2018.118 DOI: 10.1180/mgm.2018.118
  3. 2022(2022) Straßmannite. Handbook of Mineralogy. Mineralogical Society of America
