Strontioborite

Sr[B8O11(OH)4]
IMA status
  • Approved
IMA symbol
Srbo
Discovered
1960
Also known as
  • IMA2020-017
  • Strontioboriet
  • Strontioborita

Where it forms, where it's found

Geological setting

salt dome

Type locality
Chelkar salt dome
  1. Aksai Valley
  2. Terekti District
  3. West Kazakhstan Region
  4. Kazakhstan

50.4667°, 51.6833°

1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Colourless
Streak
white
Tenacity
very brittle
Cleavage
Perfect

Perfect, mica-like cleavage on (100)

stepped or laminated

Fracture
Step-Like
Density
2.40 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 85° · 2V calc = 77.5°
Refractive index
1.47 – 1.579
Surface relief
Moderate
Principal indices
nα 1.470 · nβ 1.510 · nγ 1.579
Pleochroism
Non-pleochroic
Dispersion
relatively weak
UV response
non-fluorescent under ultraviolet light or an electron beam
Michel-Lévy diagramhighlighted lineδ = 0.1090
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1090 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1090 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21
Cell parameters
a = 7.6192(3) Å · b = 8.1867(2) Å · c = 9.9164(3) Å
Cell angles
β = 108.357(4) °
Ratio a:b:c
1 : 1.074 : 1.302
Z
2
Type-locality form

lamellar, scaly or tabular crystals up to 2 mm across

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1515.999239.985
57.40%
38SrStrontiumStrontium187.62087.620
20.96%
5BBoronBoron810.81086.480
20.68%
1HHydrogenHydrogen41.0084.032
0.96%
Total418.117100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2020-017
  • Strontioboriet
  • Strontioborita

In other languages

German
IMA 2020-017 · Strontioborit
Italian
stronzioborite

Classification

Strunz
10th ed.

6.FC.10

  • 6BoratesClass
  • 6.FHexaboratesDivision
  • 6.FCPhyllo-hexaboratesGroup
  • 6.FC.10StrontioboriteSpecies
Dana
8th ed.

25.06.03.01

  • 25Anhydrous Borates Containing Hydroxyl or HalogenClass
  • 25.06HexaboratesType
  • 25.06.03— unnamed intermediate level —Group
  • 25.06.03.01StrontioboriteSpecies
CIM

9.3.26

  • 9BoratesClass
  • 9.3Borates of Ca and SrGroup
  • 9.3.26StrontioboriteSpecies

Literature, links & citation

Citations
  1. 1960Lobanova, V.V. (1960) A new borate-strontioborite. Doklady Akademii Nauk SSSR: l35: 173-175.
  2. 1961Fleischer, M. (1961) New mineral names. American Mineralogist, 46 (5-6). 765-770
  3. 1964Kondrat'eva, V.V. (1964) Unit cell and space group of strontioborite. Kristallografiya: 91: 916-917. (in Russian)
  4. 1965Fleischer, Michael (1965) New Mineral Names. American Mineralogist, 50 (9) 1504-1508
  5. 1975Brovkin, A.A., Zayakina, N.V., Brovkina, V.S. (1975) Crystal structure of strontioborite Sr[B8O11(OH)4]. Soviet Physics - Crystallography: 20: 563-566.
