Suredaite

PbSnS3
IMA status
  • Approved
IMA symbol
Su
IMA approved
1997
Also known as
  • IMA1997-043
  • Suredaiet

Where it forms, where it's found

Geological setting

Vein system in a silver–tin deposit.

Type locality
Oploca Vein System
  1. San Miguel Open pit
  2. Pirquitas Mine
  3. Mina Pirquitas
  4. Rinconada Department
  5. Jujuy Province
  6. Argentina

-22.6889°, -66.5417°

2recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789102.5 – 3/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Metallic
Transparency
Opaque
Colour
Grayish black
Streak
dark gray
Tenacity
brittle
Cleavage
Perfect

Parallel (001), (101), and (100).

Density
5.54 g/cm³

Optical

Pleochroism
Non-pleochroic
Optical colour
White
Anisotropism
weak - metallic blue to mauve to brown
Bireflectance
None
Tropism
Anisotropic
Reflectance R%
(34.3, 36.3) 460, (31.5, 33.1) 540, (30.3, 31.7) 580, (29.0, 30.2) 640
Notes

Between crossed polars its characteristic rotation tints are metallic blue to mauve to brown.

Reflected-light panel
31.3 %anisotropic · dual curve
Specimen sRGB 196, 141, 82
White reference100 % reflector under same lamp
R₁ R₂
Mode
Bireflectance
None
Anisotropism
weak - metallic blue to mauve to brown
Reflected colour
White

Crystallography

Crystal system
Orthorhombic
Space group
Pnma
Cell parameters
a = 8.8213(3) Å · b = 3.7728(3) Å · c = 14.0076(3) Å
Ratio a:b:c
1 : 0.428 : 1.588
Z
4
Morphology

aggregates of radially arranged tabular-prismatic crystals

Type-locality form

Layers up to 1 cm thickness which are composed of tabular prismatic crystals, elongated along [010] and intergrown in fan-shaped arrangements, and as individual euhedral almost needle-like crystals, embedded in sphalerite.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead1207.200207.200
49.09%
50SnTinTin1118.710118.710
28.12%
16SSulfurSulfur332.06096.180
22.79%
Total422.090100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1997-043
  • Suredaiet

In other languages

German
IMA 1997-043 · Suredait
Spanish
suredaíta
Italian
Suredaite

Classification

Strunz
10th ed.

2.DB.10

  • 2Sulfides and SulfosaltsClass
  • 2.DMetal Sulfides, M: S = 3 :4 and 2:3Division
  • 2.DBM:S = 2:3Group
  • 2.DB.10SuredaiteSpecies

Literature, links & citation

Citations
  1. 2000Paar, Werner H., Miletich, Ronald, Topa, Dan, Criddle, Alan J., De Brodtkorb, Milka K., Amthauer, Georg, Tippelt, Gerold (2000) Suredaite, PbSnS3, a new mineral species, from the Pirquitas Ag-Sn deposit, NW-Argentina: mineralogy and crystal structure. American Mineralogist, 85 (7) 1066-1075 doi:10.2138/am-2000-0723 DOI: 10.2138/am-2000-0723
  2. 2021(2021) Suredaite. Handbook of Mineralogy. Mineralogical Society of America
