Sussexite

Mn2+BO2(OH)
IMA status
  • Approved
  • Grandfathered
IMA symbol
Ssx
Discovered
1868
Also known as
  • Sussexiet

Where it forms, where it's found

Geological setting

Hydrothermal veinlets traversing Precambrian metamorphosed Zn-Mn-Fe orebody (Franklin, NJ).

Type locality
Trotter Mine
  1. Franklin Mine
  2. Franklin
  3. Sussex County
  4. New Jersey
  5. USA

41.1178°, -74.5875°

25recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
White · lilac / lavender · black (perhaps due to alteration or inclusions) · also golden-brown · colourless in transmitted light

May be orange due to zincite inclusions

Streak
White
Fracture
Sub-Conchoidal · Fibrous
Density
3.30 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 25°
Refractive index
1.67 – 1.732
Surface relief
High
Principal indices
nα 1.670 · nβ 1.728 · nγ 1.732
Birefringence
0.062
Dispersion
r > v strong
UV response
Not fluorescent in UV
Michel-Lévy diagramhighlighted lineδ = 0.0620
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]620 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation620 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
P21 21 2
Cell parameters
a = 10.70 Å · b = 12.77 Å · c = 3.25 Å
Ratio a:b:c
1 : 1.193 : 0.304
Z
8
Morphology

Veinlets and masses with a felted or matted fibrous structure; also parallel-fibrous or transverse-fibrous veinlets. Chert-like masses. Microscopically observed as minute laths or flattened fibers.

Type-locality form

Fibrous, sometimes asbestiform.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
25MnManganeseManganese154.93854.938
47.87%
8OOxygenOxygen315.99947.997
41.83%
5BBoronBoron110.81010.810
9.42%
1HHydrogenHydrogen11.0081.008
0.88%
Total114.753100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Mg

Synonyms

  • Sussexiet

In other languages

French
Sussexite
German
Sussexit
Spanish
Sussexita
Italian
Sussexite
Chinese
白硼镁锰矿

Classification

Strunz
10th ed.

6.BA.15

  • 6BoratesClass
  • 6.BDiboratesDivision
  • 6.BANeso-diborates with double triangles B2(O,OH)5; 2(2D); 2(2D) + OH, etc.Group
  • 6.BA.15SussexiteSpecies
Dana
8th ed.

25.02.01.01

  • 25Anhydrous Borates Containing Hydroxyl or HalogenClass
  • 25.02DiboratesType
  • 25.02.01— unnamed intermediate level —Group
  • 25.02.01.01SussexiteSpecies
CIM

9.7.4

  • 9BoratesClass
  • 9.7Borates of MnGroup
  • 9.7.4SussexiteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1868Brush, G.J. (1868) New borate from Mine Hill, Franklin, Sussex Co.,N.J. - Sussexite. American Journal of Science, 2nd. series: 46: 140-140.
  2. 1868Brush, G.J. (1868) On sussexite, a new borate from Mine Hill, Franklin Furnace, Sussex Co., New Jersey. American Journal of Science and Arts: 96: 240-243.
  3. 1888Penfield, S.L., Sperry, E.S. (1888) Mineralogical notes (Sussexite from Mine Hill, Franklin, N.J.). American Journal of Science: 36: 317-331 (323).
  4. 1924Poitevin, Eugene, Ellsworth, H. V. (1924) New optical data for analyzed sussexite. American Mineralogist, 9 (9) 188-189
  5. 1928Palache, C. (1928) Mineralogical notes on Franklin and Sterling Hill, New Jersey. American Mineralogist, 13 (7) 297-329
