Swedenborgite

NaBe4Sb5+O7
IMA status
  • Approved
  • Grandfathered
IMA symbol
Swe
Discovered
1924
Also known as
  • Swedenborgiet

Where it forms, where it's found

Geological setting

Skarn in a metamorphosed Fe-Mn ore body.

Type locality
Långban Mine
  1. Långban Ore District
  2. Filipstad
  3. Värmland County
  4. Sweden

59.8554°, 14.2648°

2recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789108/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Colourless · pale wine- to honey-yellow · colourless in transmitted light
Cleavage
Distinct/Good

On (0001), distinct.

Fracture
Sub-Conchoidal
Density
4.285 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.77 – 1.7724
Surface relief
High
Principal indices
nω 1.7724 · nε 1.77
Dispersion
Strong
UV response
Fluoresces deep red under LW/MW UV, and deep blue under SW UV.
Michel-Lévy diagramhighlighted lineδ = 0.0024
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]24 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation24 nm
Order1st order
XPL colour

Crystallography

Crystal system
Hexagonal
Space group
#114
Cell parameters
a = 5.442 Å · c = 8.848 Å
Z
2
Morphology

Crystals short prismatic (1010), (1011), and (0001) prominent. May be morphologically hemihedral with c and p unequally developed at opposite terminations of (0001) at times.

Twinning

Observed, not described.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
51SbAntimonyAntimony1121.760121.760
41.59%
8OOxygenOxygen715.999111.993
38.25%
4BeBerylliumBeryllium49.01236.048
12.31%
11NaSodiumSodium122.99022.990
7.85%
Total292.791100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Swedenborgiet

In other languages

German
Swedenborgit
Spanish
Swedenborgita
Italian
Swedenborgite

Classification

Strunz
10th ed.

4.AC.05

  • 4OxidesClass
  • 4.AMetal: Oxygen = 2:1 and 1:1Division
  • 4.ACM:O = 1:1 (and up to 1:1.25); with large cations (+- smaller ones)Group
  • 4.AC.05SwedenborgiteSpecies
Dana
8th ed.

44.03.01.01

  • 44AntimonatesClass
  • 44.03MiscellaneousType
  • 44.03.01— unnamed intermediate level —Group
  • 44.03.01.01SwedenborgiteSpecies
CIM

24.2.1

  • 24Antimonates and AntimonitesClass
  • 24.2Antimonates of Be, Mg, Ca, Zn or HgGroup
  • 24.2.1SwedenborgiteSpecies

Literature, links & citation

Citations
  1. 1924Aminoff, G., Almström, G. Karl (1924) X. Über ein neues Mineral von Långban. Zeitschrift für Kristallographie - Crystalline Materials, 60 (1). 262-274 doi:10.1524/zkri.1924.60.1.262DOI: 10.1524/zkri.1924.60.1.262
  2. 1925Foshag, W.F. (1925) New minerals: new species. American Mineralogist, 10, 39-41.
  3. 1925Gossner (1925) Centralblatt für Mineralogie, Geologie und Paleontologie, Stuttgart: 289 (morphological resemblance to corundum).
  4. 1933Aminoff (1933) Svenska Vetenskapsakademien, Stockholm, Handlingar: [3]: 11(4): 3.
  5. 1934Foshag, W.F. (1934) New mineral names. American Mineralogist, 19 (6). 287-288
