Takedaite

Ca3B2O6
IMA status
  • Approved
IMA symbol
Tkd
Discovered
1993
IMA approved
1993
Also known as
  • IMA1993-049
  • Takedaiet

Where it forms, where it's found

Geological setting

A vein of borate minerals along a boundary between crystalline limestone and skarn.

Type locality
Fuka mine
  1. Fuka
  2. Bitchū
  3. Takahashi City
  4. Okayama Prefecture
  5. Japan

34.7882°, 133.4429°

1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Translucent
Colour
White to pale grey
Streak
White
Density
3.10 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.63 – 1.726
Surface relief
High
Principal indices
nω 1.726 · nε 1.630
Michel-Lévy diagramhighlighted lineδ = 0.0960
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]960 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation960 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
R-3c
Cell parameters
a = 8.638(1) Å · c = 11.850(2) Å
Z
6
Type-locality form

Aggregates of granular crystals up to 0.8 mm long.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
20CaCalciumCalcium340.078120.234
50.55%
8OOxygenOxygen615.99995.994
40.36%
5BBoronBoron210.81021.620
9.09%
Total237.848100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1993-049
  • Takedaiet

In other languages

German
IMA 1993-049 · Takedait
Italian
Takedaite
Japanese
武田石
Chinese
武田石

Classification

Strunz
10th ed.

6.AA.40

  • 6BoratesClass
  • 6.AMonoboratesDivision
  • 6.AABO3, without additional anions; 1(D).Group
  • 6.AA.40TakedaiteSpecies
Dana
8th ed.

24.03.05.01

  • 24Anhydrous BoratesClass
  • 24.03AmBn[XO3]pType
  • 24.03.05— unnamed intermediate level —Group
  • 24.03.05.01TakedaiteSpecies

Literature, links & citation

Citations
  1. 1969Schuckmann, W. (1969) Zur Kristallstruktur des Calcium-Borates Ca3(BO3)2. Neues Jahrbuch für Mineralogie, Monatshefte: 1969: 142-143.
  2. 1975Vegas, A., Cano, F. H., García-Blanco, S. (1975) The crystal structure of calcium orthoborate: a redetermination. Acta Crystallographica Section B Structural Crystallography and Crystal Chemistry, 31 (5) 1416-1419 doi:10.1107/s0567740875005316DOI: 10.1107/s0567740875005316
  3. 1995Kusachi, I., Henmi, C., Kobayashi, S. (1995) Takedaite, a new mineral from Fuka, Okayama Prefecture, Japan. Mineralogical Magazine, 59 (396) 549-552 doi:10.1180/minmag.1995.059.396.15 DOI: 10.1180/minmag.1995.059.396.15
  4. 1996Mandarino, Joseph A. (1996) Abstracts of New Mineral Descriptions. The Mineralogical Record, 27 (4) 301-306
  5. 1996Grew, Edward S.; Anovitz, Lawrence M. - Eds. (1996) Boron - Mineralogy, Petrology and Geochemistry. Reviews in Mineralogy Vol. 33. Mineralogical Society of America p.862
