Taniajacoite

SrCaMn3+2Si4O11(OH)4 · 2H2O
IMA status
  • Approved
IMA symbol
Tjc
IMA approved
2015
Also known as
  • IMA2014-107
  • Taniajacoiet

Where it forms, where it's found

Type locality
N'Chwaning III Mine
  1. N'Chwaning Mines
  2. Joe Morolong Local Municipality
  3. John Taolo Gaetsewe District Municipality
  4. Northern Cape
  5. South Africa

-27.1345°, 22.8461°

1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105 – 5.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Brown
Streak
Very light brown
Tenacity
brittle
Cleavage
Distinct/Good

Good on (010)

Density
3.05 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 63.7° · 2V calc = 62.5°
Refractive index
1.686 – 1.746
Surface relief
High
Principal indices
nα 1.686 · nβ 1.729 · nγ 1.746
Michel-Lévy diagramhighlighted lineδ = 0.0600
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]600 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation600 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Triclinic
Cell parameters
a = 9.1386(5) Å · b = 6.2566(3) Å · c = 12.0043(6) Å
Cell angles
α = 90.019(4) ° · β = 91.643(4) ° · γ = 89.900(4) °
Ratio a:b:c
1 : 0.685 : 1.314
Unit cell volume
686.08 ų
Twinning

No macroscopic twinning.

Parting
None
Type-locality form

Radiating acicular brown crystals.

Comment

Non-standard space-group setting C1, to allow easier comparison with other, monoclinic (C2) members of the ruizite group. Pseudomonoclinic.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1715.999271.983
43.18%
14SiSiliconSilicon428.085112.340
17.83%
25MnManganeseManganese254.938109.876
17.44%
38SrStrontiumStrontium187.62087.620
13.91%
20CaCalciumCalcium140.07840.078
6.36%
1HHydrogenHydrogen81.0088.064
1.28%
Total629.961100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2014-107
  • Taniajacoiet

In other languages

German
IMA 2014-107 · Taniajacoit
Italian
taniajacoite

Classification

Strunz
10th ed.

9.BJ.35

  • 9SilicatesClass
  • 9.BSorosilicatesDivision
  • 9.BJSorosilicates with Si3O10, Si4O11, etc. anions; cations in octahedral [6] and greater coordinationGroup
  • 9.BJ.35TaniajacoiteSpecies

Group, growth & confusion

In the same group
2 members
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 2015Hålenius, U., Hatert, F., Pasero, M., Mills, S. J. (2015) New minerals and nomenclature modifications approved in 2015, CNMNC Newsletter No 25. Mineralogical Magazine, 79 (3) 529-535 doi:10.1180/minmag.2015.079.3.02DOI: 10.1180/minmag.2015.079.3.02
  2. 2016rruff.info (n.d.) http://rruff.info/taniajacoite/display=default
  3. 2021Yang, Hexiong, Gu, Xiangping, Cairncross, Bruce, Downs, Robert T., Evans, Stanley H. (2021) Taniajacoite and strontioruizite, two new minerals isostructural with ruizite from the N'Chwaning III Mine, Kalahari Manganese Field, South Africa. The Canadian Mineralogist, 59 (2) 431-444 doi:10.3749/canmin.2000037 DOI: 10.3749/canmin.2000037
  4. 2022(2022) Taniajacoite. Handbook of Mineralogy. Mineralogical Society of America
