Tapiaite

Ca5Al2(AsO4)4(OH)4 · 12H2O
IMA status
  • Approved
IMA symbol
Tpi
IMA approved
2014
Also known as
  • IMA2014-024
  • Tapiaiet

Where it forms, where it's found

Geological setting

The mineral is a late-stage, low-temperature, secondary mineral occurring in narrow seams and vughs in the oxidized upper portion of a hydrothermal sulfide vein hosted by volcanoclastic rocks.

Type locality
Jote Mine
  1. Pampa Larga mining district
  2. Tierra Amarilla
  3. Copiapó Province
  4. Atacama
  5. Chile

-27.6086°, -70.1564°

3recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789102 – 3/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
colorless
Streak
white
Tenacity
brittle
Cleavage
Perfect

two perfect cleavages on (101) and (101)

Fracture
Splintery
Density
2.681 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 66° · 2V calc = 66°
Refractive index
1.579 – 1.61
Surface relief
Moderate
Principal indices
nα 1.579 · nβ 1.588 · nγ 1.610
Pleochroism
Non-pleochroic
Dispersion
none
Michel-Lévy diagramhighlighted lineδ = 0.0310
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]310 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation310 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 16.016(1) Å · b = 5.7781(3) Å · c = 16.341(1) Å
Cell angles
β = 116.704(8) °
Ratio a:b:c
1 : 0.361 : 1.020
Z
2
Type-locality form

blades, flattened on {101¯} and elongated and striated along [010], up to ~0.5 mm long, and exhibiting the forms {101¯}, (101) and (111). The blades are commonly intergrown in subparallel bundles and less commonly in sprays.

Comment

P21/n

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen3215.999511.968
46.79%
33AsArsenicArsenic474.922299.688
27.39%
20CaCalciumCalcium540.078200.390
18.31%
13AlAluminiumAluminium226.98253.964
4.93%
1HHydrogenHydrogen281.00828.224
2.58%
Total1094.234100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2014-024
  • Tapiaiet

In other languages

German
IMA 2014-024 · Tapiait
Italian
tapiaite

Classification

Strunz
10th ed.

8.DM.55

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.DPhosphates, etc. with additional anions, with H2ODivision
  • 8.DMWith large and medium-sized cations, (OH, etc.):RO4 > 2:1Group
  • 8.DM.55TapiaiteSpecies

Literature, links & citation

Citations
  1. 2014Williams, P. A., Hatert, F., Pasero, M., Mills, S. J. (2014) New minerals and nomenclature modifications approved in 2014, CNMNC Newsletter No 21. Mineralogical Magazine, 78 (4) 797-804 doi:10.1180/minmag.2014.078.4.03DOI: 10.1180/minmag.2014.078.4.03
  2. 2015Kampf, Anthony R., Mills, Stuart J., Nash, Barbara P., Dini, Maurizio, Molina Donoso, Arturo A. (2015) Tapiaite, Ca5Al2(AsO4)4(OH)4·12H2O, a new mineral from the Jote mine, Tierra Amarilla, Chile. Mineralogical Magazine, 79 (2) 345-354 doi:10.1180/minmag.2015.079.2.12 DOI: 10.1180/minmag.2015.079.2.12
  3. 2017(2017) Tapiaite. Handbook of Mineralogy. Mineralogical Society of America
