Taramellite

Ba4(Fe3+,Ti)4O2[B2Si8O27]Clx
IMA status
  • Approved
  • Grandfathered
IMA symbol
Tmel
Discovered
1908

Where it forms, where it's found

Geological setting

metamorphic rocks rich in barium silicates, in contact with granitic rocks

Type locality
Candoglia marble quarries
  1. Candoglia
  2. Mergozzo
  3. Verbano-Cusio-Ossola Province
  4. Piedmont
  5. Italy

45.9819°, 8.4257°

8recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Red-brown
Cleavage
Perfect

Perfect on (100)

Density
3.92 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 40° · 2V calc = 32°
Refractive index
1.77 – 1.83
Surface relief
Very high
Principal indices
nα 1.770 · nβ 1.774 · nγ 1.83
Pleochroism
Strong

X = Y = pale pinkish to flesh-red; Z = dark brown to nearly black.

Dispersion
r > v distinct
Michel-Lévy diagramhighlighted lineδ = 0.0600
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]600 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation600 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
Pmmn
Cell parameters
a = 12.05 Å · b = 13.9 Å · c = 7.12 Å
Ratio a:b:c
1 : 1.154 : 0.591
Z
2
Morphology

Tabular to equidimensional crystals; as fibrous aggregates and massive.

Parting
Perpendicular to (100)
Crystal structure

Chemical composition

Impurities
  • Mn
  • Pb
  • Ca
  • Na
  • K
  • H2O

In other languages

German
Taramellit
Italian
Taramellite
Chinese
纤硅钡高铁石

Classification

Strunz
10th ed.

9.CE.20

  • 9SilicatesClass
  • 9.CCyclosilicatesDivision
  • 9.CE[Si4O12]8- 4-membered single rings (vierer-Einfachringe), without insular complex anionsGroup
  • 9.CE.20TaramelliteSpecies
Dana
8th ed.

64.03.01.01

  • 64Cyclosilicates Rings with Other Anions and Insular Silicate GroupsClass
  • 64.03Rings with Other Anions and Insular Silicate Groups: 4-membered rings with [Si2O7] dimersType
  • 64.03.01Taramellite groupGroup
  • 64.03.01.01TaramelliteSpecies
CIM

17.5.34

  • 17Silicates Containing other AnionsClass
  • 17.5BorosilicatesGroup
  • 17.5.34TaramelliteSpecies

Group, growth & confusion

Often grow together
1 mineral

Literature, links & citation

Citations
  1. 1908Tacconi, E. (1908): Ueber Taramellit, ein neues Mineral. Centralblatt für Mineralogie, Geologie und Paläontologie, 1908, 506-508
  2. 1908Atti R. Accad. Lincei. Rend. Cl. Sci. fis. mat. nat., Roma (1908), ser.5, 17, 810.
  3. 1959American Mineralogist (1959): 44: 469.
  4. 1965Mazzi, Fiorenzo, Rossi, Giuseppe (1965) The crystal structure of taramellite Ba2(Fe,Ti,Mg)2H2[O2(Si4O12)]. Zeitschrift für Kristallographie - Crystalline Materials, 121 (2) 243-257 doi:10.1524/zkri.1965.121.2-4.243 DOI: 10.1524/zkri.1965.121.2-4.243
  5. 1978Pabst, A. (1978) Zur Morphologie des Taramellits. Tschermaks Mineralogische und Petrographische Mitteilungen, 25 (4). 245-256 doi:10.1007/bf01180231DOI: 10.1007/bf01180231
