Teepleite

Na2B(OH)4Cl
IMA status
  • Approved
  • Grandfathered
IMA symbol
Tee
Discovered
1938
Also known as
  • Teepleiet

Where it forms, where it's found

Geological setting

Residual brine in a lacustrine evaporite deposit after a period of extreme dessication.

Type locality
Borax Lake (Big Borax Lake)
  1. Clear Lake Oaks
  2. Sulphur Creek Mining District (Sulfur Creek Mining District
  3. Wilbur Springs Mining District)
  4. Lake County
  5. California
  6. USA

38.9883°, -122.6767°

3recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103 – 3.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Transparent · Translucent
Colour
Colourless · white · light beige · colourless in transmitted light
Streak
White
Tenacity
very brittle
Fracture
Irregular/Uneven · Sub-Conchoidal
Density
2.076 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.503 – 1.519
Surface relief
Moderate
Principal indices
nω 1.519 · nε 1.503
Michel-Lévy diagramhighlighted lineδ = 0.0160
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]160 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation160 nm
Order1st order
XPL colour

Crystallography

Crystal system
Tetragonal
Space group
#185
Cell parameters
a = 7.25 Å · c = 4.84 Å
Morphology

Crystals tabular (001). Crystals commonly rounded into cushion-shaped or lens-like forms and are often aggregated into interpenetrating groups. The only two forms observed in type material were (001) and (101).

Type-locality form

Buff colored crusts and pseudomorphs after halite.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen415.99963.996
39.93%
11NaSodiumSodium222.99045.980
28.69%
17ClChlorineChlorine135.45035.450
22.12%
5BBoronBoron110.81010.810
6.74%
1HHydrogenHydrogen41.0084.032
2.52%
Total160.268100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Teepleiet

In other languages

German
Teepleit
Italian
Teepleite

Classification

Strunz
10th ed.

6.AC.40

  • 6BoratesClass
  • 6.AMonoboratesDivision
  • 6.ACB(O,OH)4, without and with additional anions; 1(T), 1(T)+OH, etcGroup
  • 6.AC.40TeepleiteSpecies
Dana
8th ed.

25.01.04.01

  • 25Anhydrous Borates Containing Hydroxyl or HalogenClass
  • 25.01MonoboratesType
  • 25.01.04— unnamed intermediate level —Group
  • 25.01.04.01TeepleiteSpecies
CIM

10.1.1

  • 10Borates with other anionsClass
  • 10.1Borates with halideGroup
  • 10.1.1TeepleiteSpecies

Literature, links & citation

Citations
  1. 1929Teeple, J.E. (1929) The Industrial Development of Searles Lake Brines, New York: 130 (artificial material).
  2. 1939Gale, W. A., Foshag, William F., Vonsen, M. (1939) Teepleite, a new mineral from Borax Lake, California. American Mineralogist, 24 (1). 48-52
  3. 1949Fornaseri, M. (1949) La struttura cristallina della teepleite. Periodico di Mineralogia (Roma), 103-124.
  4. 1951Palache, Charles; Berman, Harry; Frondel, Clifford (1951) The System of Mineralogy (7th ed.) Vol. 2 - Halides, Nitrates, Borates, Carbonates, Sulfates, Phosphates, Arsenates, Tungstates, Molybdates, Etc. John Wiley and Sons.
  5. 1959Ross, V., Edwards, J. O. (1959) Notes and News: Tetrahedral boron in teepleite and bandylite. American Mineralogist, 44 (7-8). 875-877
