Telluromandarinoite

Fe3+2(Te4+O3)3 · 6H2O
IMA status
  • Approved
IMA symbol
Tmda
IMA approved
2011
Also known as
  • IMA2011-013
  • Telluromandarinoiet

Where it forms, where it's found

Geological setting

Hydrothermal breccias with silicified clasts of dacite tuffs cemented by silica/barite/alunite

Type locality
Wendy pit
  1. Tambo Mine
  2. Vicuña
  3. Elqui Province
  4. Coquimbo
  5. Chile

-29.8121°, -69.9495°

3recorded occurrences
Source · OpenStreetMap

Physical

Transparency
Translucent
Colour
Pale green
Streak
White
Tenacity
brittle
Cleavage
None Observed
Fracture
Irregular/Uneven
Density
3.372 g/cm³

Optical

Optical type
Biaxial (+) · 2V calc = 76.9°
Refractive index
1.75 – 1.91
Surface relief
Very high
Principal indices
nα 1.750 · nβ 1.807 · nγ 1.910
Pleochroism
Non-pleochroic
Dispersion
not noticed
Notes

optical orientation: Y = b, c ˆ Z = 10° in obtuse β

Michel-Lévy diagramhighlighted lineδ = 0.1600
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1600 nm3rd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1600 nm
Order3rd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#14
Cell parameters
a = 16.9356(5) Å · b = 7.8955(3) Å · c = 10.1678(3) Å
Cell angles
β = 98.006(1) °
Ratio a:b:c
1 : 0.466 : 0.600
Unit cell volume
1346.32 ų
Z
4
Parting
Not observed
Type-locality form

Individual platy crystals, 0.2 mm or less, often in aggregates

Comment

Structurally similar to emmonsite

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
52TeTelluriumTellurium3127.600382.800
51.27%
8OOxygenOxygen1515.999239.985
32.15%
26FeIronIron255.845111.690
14.96%
1HHydrogenHydrogen121.00812.096
1.62%
Total746.571100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2011-013
  • Telluromandarinoiet

In other languages

German
IMA 2011-013 · Telluromandarinoit
Italian
telluromandarinoite

Classification

Strunz
10th ed.

4.JM.20

  • 4OxidesClass
  • 4.JArsenites, antimonites, bismuthites, sulfites, selenites, tellurites; iodatesDivision
  • 4.JMTellurites without additional anions, with H2OGroup
  • 4.JM.20TelluromandarinoiteSpecies

Literature, links & citation

Citations
  1. 2011Williams, P. A., Hatert, F., Pasero, M., Mills, S. J. (2011) New minerals and nomenclature modifications approved in 2011, CNMNC Newsletter No. 10. Mineralogical Magazine, 75 (5) 2549-2561 doi:10.1180/minmag.2011.075.5.2549 DOI: 10.1180/minmag.2011.075.5.2549
  2. 2017Back, Malcolm E., Grice, Joel D., Gault, Robert A., Cooper, Mark A., Walford, Phillip C., Mandarino, Joseph A. (2017) Telluromandarinoite, A New Tellurite Mineral From the El Indio-Tambo Mining Property, Andes Mountains, Chile. The Canadian Mineralogist, 55 (1) 21-28 doi:10.3749/canmin.1500014DOI: 10.3749/canmin.1500014
  3. 2018(2018) Telluromandarinoite. Handbook of Mineralogy. Mineralogical Society of America
