Thomsonite-Sr

NaSr2(Al5Si5)O20 · 6-7H2O
IMA status
  • Approved
IMA symbol
Thm-Sr
IMA approved
2000
Also known as
  • IMA2000-025

Where it forms, where it's found

Geological setting

In veinlets cross-cutting natrolite of risschorrite pegmatite (Rasvumchorr). In a veinlet cross-cutting urtite, as zones in thomsonite-Ca (Yuksporr).

Type locality
Rasvumchorr Mt
  1. Murmansk Oblast
  2. Russia

67.6000°, 33.9000°

4recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Colorless
Streak
White
Tenacity
brittle
Cleavage
Perfect

[100] Perfect, [010] Good

Density
2.47 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 62° · 2V calc = 72°
Refractive index
1.528 – 1.54
Surface relief
Moderate
Principal indices
nα 1.528 · nβ 1.532 · nγ 1.54
Pleochroism
Non-pleochroic
Dispersion
weak, r > v
Extinction
X = a, Y = c, Z = b.
Michel-Lévy diagramhighlighted lineδ = 0.0120
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]120 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation120 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 13.050 Å · b = 13.123 Å · c = 13.241 Å
Ratio a:b:c
1 : 1.006 : 1.015
Z
4
Morphology

Forms: (100), (010), {0О1}, (110).

Twinning

None observed.

Type-locality form

Euhedral prismatic crystals up to 1.0 x 0.2 x 0.2 mm (Rasvumchorr) and zones up to 0.02 mm (Yuksporr).

Comment

Non-standard space-group setting Pcnn.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2615.999415.974
46.14%
38SrStrontiumStrontium287.620175.240
19.44%
14SiSiliconSilicon528.085140.425
15.57%
13AlAluminiumAluminium526.982134.910
14.96%
11NaSodiumSodium122.99022.990
2.55%
1HHydrogenHydrogen121.00812.096
1.34%
Total901.635100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2000-025

In other languages

German
IMA 2000-025 · Thomsonit-Sr
Italian
IMA2000-025 · thomsonite-Sr
Chinese
锶杆沸石

Classification

Strunz
10th ed.

9.GA.10

  • 9SilicatesClass
  • 9.GTektosilicates with zeolitic H2O; zeolite familyDivision
  • 9.GAZeolites with T5O10 Units – The Fibrous ZeolitesGroup
  • 9.GA.10Thomsonite-SrSpecies

Group, growth & confusion

In the same group
1 members

Literature, links & citation

Citations
  1. 2001Pekov, I. V., Lovskaya, E. V., Turchkova, A. G., Chukanov, N. V., Zadov, A. E., Rastsvetaeva, R. K., Kononkova, N. N. (2001) Thomsonite-Sr (Sr,Ca)2Na[Al2Si5O20]·6–7H2O, a new zeolite mineral from Khibiny Massif (Kola Peninsula) and thomsonite-Ca—thomsonite-Sr an isomorphous series. Zapiski Vserossijskogo Mineralogicheskogo Obshchestva, 130 (4) 46-55
  2. 2001Gurbanova, O. A., Rastsvetaeva, R. K., Pekov, I. V., Turchkova, A. G. (2001) Crystal structure of strontium-rich thomsonite. Doklady Earth Sciences, 376. 101-104
  3. 2001Gurbanova, O. A., Rastsvetaeva, R. K., Pekov, I. V., Turchkova, A. G. (2001) Crystal structure of strontium-rich thomsonite. Doklady Akademii Nauk, 376. 387-390
  4. 2001Jambor, John L., Roberts, Andrew C. (2001) New mineral names. American Mineralogist, 86 (9) 1112-1115
  5. 2002Jambor, John L., Grew, Edward S., Roberts, Andrew C. (2002) New mineral names. American Mineralogist, 87. 1509-1513
