Tongbaite

Cr3C2
IMA status
  • Approved
IMA symbol
Tgb
Discovered
1982
IMA approved
1982
Also known as
  • IMA1982-003
  • Tongbaiet

Where it forms, where it's found

Geological setting

Ultramafic rocks

Type locality
Liu village
  1. Tongbai County
  2. Nanyang
  3. Henan
  4. China
1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789108.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Brownish yellow
Streak
Dark gray
Tenacity
brittle
Density
6.64 g/cm³

Optical

Optical type
Biaxial
Pleochroism
Visible
Optical colour
Pale violet
Anisotropism
Strong; purplish yellow to yellow-orange.
Bireflectance
Distinct
Tropism
Anisotropic
Reflectance R%
(46.54,49.10) 405, (48.50,51.28) 436, (51.14,53.86) 480, (53.72,55.94) 526, (54.68,56.89) 546, (57.07,57.51) 578, (57.38,57.82) 589, (58.72,57.68) 622, (60.33,59.02) 644, (61.50,59.97) 656, (61.56,59.97) 664, (61.35,59.20) 700
Reflected-light panel
56.0 %anisotropic · dual curve
Specimen sRGB 255, 181, 93
White reference100 % reflector under same lamp
R₁ R₂
Mode
Bireflectance
Distinct
Anisotropism
Strong; purplish yellow to yellow-orange.
Reflected colour
Pale violet

Crystallography

Crystal system
Orthorhombic
Space group
Pnma
Cell parameters
a = 5.57(5) Å · b = 11.47(8) Å · c = 2.816(8) Å
Ratio a:b:c
1 : 2.059 : 0.506
Z
4
Type-locality form

Prismatic, pseudohexagonal crystals, to 0.3 mm.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
24CrChromiumChromium351.996155.988
86.66%
6CCarbonCarbon212.01124.022
13.34%
Total180.010100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1982-003
  • Tongbaiet

In other languages

German
IMA 1982-003 · Tongbait
Italian
Tongbaite
Japanese
トンバイ鉱
Arabic
تونبيت · تونغبيت

Classification

Strunz
10th ed.

1.BA.15

  • 1ElementsClass
  • 1.BMetallic Carbides, Silicides, Nitrides, Phosphides and HydridesDivision
  • 1.BACarbidesGroup
  • 1.BA.15TongbaiteSpecies
Dana
8th ed.

01.01.17.01

  • 01Native Elements and AlloysClass
  • 01.01Metals, other than the Platinum GroupType
  • 01.01.17— unnamed intermediate level —Group
  • 01.01.17.01TongbaiteSpecies
CIM

2.4

  • 2Carbides, Nitrides, Silicides and PhosphidesClass
  • 2.4— unnamed intermediate level —Group
  • 2.4TongbaiteSpecies

Literature, links & citation

Citations
  1. 1969Rundqvist, S., Runnsjö, G. (1969) Crystal structure refinement of Cr3C2. Acta Chemica Scandinavica: 23: 1191-1199.
  2. 1983Peixue, Tian; Qingsong, Fang; Keqiao, Chen; Zhizhong, Peng (1983) A study on tongbaite - a new mineral. Acta Mineralogica Sinica: 3: 241-245. (in Chinese with English abstract)
  3. 1983Chen Keqiao, Tian Peixue, Shi Nicheng, and Peng Zhizhong (1983): A study on tongbaite, Cr3C2 - A new mineral. Ziran Zazhi: 6: 478-479.
  4. 1983Tian Peixue, Fang Qingsong, Chen Keqiao, and Peng Zhizhong (1983): A study on tongbaite - A new mineral. Acta Mineralogica Sinica 3(4), 241-245
  5. 1985Dunn, Pete J., Chao, George Y., Fleischer, Michael, Ferraiolo, James A., Langley, Richard H., Pabst, Adolf, Zilczer, Janet A. (1985) New mineral names. American Mineralogist, 70 (1-2) 214-221
