Törnebohmite-(Ce)

Ce2Al(SiO4)2(OH)
IMA status
  • Approved
  • Grandfathered
IMA symbol
Tbh-Ce
Also known as
  • Törnebohmiet-(Ce)

Where it forms, where it's found

Type locality
Bastnäs Mines
  1. Riddarhyttan
  2. Skinnskatteberg
  3. Västmanland County
  4. Sweden

59.8468°, 15.5896°

29recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Olive-green · brown
Density
4.94 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 26° · 2V calc = 56°
Refractive index
1.845 – 1.878
Surface relief
Very high
Principal indices
nα 1.845 · nβ 1.852 · nγ 1.878
Pleochroism
Strong

Very strong; X = light rose to greenish yellow; Y = bluish green; Z = light rose.

Dispersion
strong
Notes

Absorption: Y > X = Z.

Michel-Lévy diagramhighlighted lineδ = 0.0330
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]330 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation330 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/c
Cell parameters
a = 7.383(3) Å · b = 5.673(3) Å · c = 16.937(6) Å
Cell angles
β = 112.04 °
Ratio a:b:c
1 : 0.768 : 2.294
Type-locality form

Fine-grained, massive; as inclusions in cerite.

Comment

Pseudohexagonal

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
58CeCeriumCerium2140.116280.232
55.12%
8OOxygenOxygen915.999143.991
28.32%
14SiSiliconSilicon228.08556.170
11.05%
13AlAluminiumAluminium126.98226.982
5.31%
1HHydrogenHydrogen11.0081.008
0.20%
Total508.383100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Törnebohmiet-(Ce)

In other languages

German
Törnebohmit-(Ce)
Italian
Törnebohmite- · Törnebohmite-(Ce)

Classification

Strunz
10th ed.

9.AG.45

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.AGNesosilicates with additional anions; cations in > [6] +- [6] coordinationGroup
  • 9.AG.45Törnebohmite-(Ce)Species
Dana
8th ed.

52.04.05.01

  • 52Nesosilicates Insular Sio4 Groups and O, Oh, F, H2oClass
  • 52.04Insular SiO4 Groups and O, OH, F, and H2O with cations in [6] and/or >[6] coordinationType
  • 52.04.05Tornebohmite groupGroup
  • 52.04.05.01Törnebohmite-(Ce)Species
CIM

16.13.2

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.13Aluminosilicates of the rare earthsGroup
  • 16.13.2Törnebohmite-(Ce)Species

Literature, links & citation

Citations
  1. 1920Geijer, P. (1920) The cerium minerals of Bastnäs at Riddarhyttan. Sveriges Geologiska Undersökning Arsbok: 14(304): 1-24.
  2. 1921Wherry, E.T. (1921) New minerals. American Mineralogist: 6: 118-119.
  3. 1966Levinson, A. A. (1966) A system of nomenclature for rare-earth minerals. American Mineralogist, 51 (1-2) 152-158
  4. 1982Shen, J., Moore, P. B. (1982) Törnebohmite, RE2Al(OH)[SiO4]2: crystal structure and genealogy of RE(III)Si(IV)‹—›Ca(II)P(V) isomorphisms. American Mineralogist, 67 (9-10) 1021-1028
  5. 1987Nickel, Ernest H., Mandarino, Joseph A. (1987) Procedures involving the IMA Commission on New Minerals and Mineral Names and guidelines on mineral nomenclature. American Mineralogist, 72 (9-10) 1031-1042
Cite this entry
@misc{mineral2026,
  author    = {Mineral Index editorial board},
  title     = {Törnebohmite-(Ce) — Mineral Index},
  year      = {2026},
  url       = {https://mineralindex.org/minerals/tornebohmite-ce-3998},
  note      = {Accessed 2026-05-11}
}
