Torreyite

Mg9Zn4(SO4)2(OH)22 · 8H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Try
Discovered
1949
Also known as
  • Delta-mooreite
  • Torreyiet

Where it forms, where it's found

Geological setting

Secondary veinlets and fractures in a Pre-cambrian metamorphosed Zn-Mn-Fe deposit.

Type locality
Sterling Mine
  1. Sterling Hill
  2. Ogdensburg
  3. Sussex County
  4. New Jersey
  5. USA

41.0836°, -74.6047°

1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Rarely colourless · white · usually light brown with a red gray tint · rarely very pale blue gray · colourless in transmitted light.

May be tan to light brown as a surface coating when slightly oxidized.

Streak
White to colorless
Tenacity
brittle
Cleavage
Distinct/Good

On (010), good.

Micaceous is an accurate description of the cleavage except that the folia are not broad as in a platy mica, but the cleavage follows the rod-like habit common to the mineral.

Fracture
Micaceous
Density
2.665 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 40° · 2V calc = 28°
Refractive index
1.57 – 1.585
Surface relief
Moderate
Principal indices
nα 1.570 · nβ 1.584 · nγ 1.585
Birefringence
0.015
Pleochroism
Non-pleochroic
Dispersion
r > v
UV response
Not fluorescent in UV
Notes

Refractive index is decidedly higher than mooreite

Michel-Lévy diagramhighlighted lineδ = 0.0150
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]150 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation150 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/c
Cell parameters
a = 10.522 Å · b = 9.433 Å · c = 16.443 Å
Cell angles
β = 94.91 °
Ratio a:b:c
1 : 0.897 : 1.563
Z
2
Morphology

Massive; granular to foliated.

Twinning

Intricately polysynthetically twinned with twin plane in the zone [010] (visible under magnification).

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen3815.999607.962
51.06%
30ZnZincZinc465.380261.520
21.96%
12MgMagnesiumMagnesium924.305218.745
18.37%
16SSulfurSulfur232.06064.120
5.39%
1HHydrogenHydrogen381.00838.304
3.22%
Total1190.651100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Delta-mooreite
  • Torreyiet

In other languages

German
Torreyit
Italian
Torreyite

Classification

Strunz
10th ed.

7.DD.40

  • 7SulfatesClass
  • 7.DSulfates (selenates, etc.) with additional anions, with H2ODivision
  • 7.DDWith only medium-sized cations; sheets of edge-sharing octahedraGroup
  • 7.DD.40TorreyiteSpecies
Dana
8th ed.

31.01.04.01

  • 31Hydrated Sulfates Containing Hydroxyl or HalogenClass
  • 31.01(AB)m(XO4)pZq·xH2O, where m:p > 6:1Type
  • 31.01.04— unnamed intermediate level —Group
  • 31.01.04.01TorreyiteSpecies
CIM

25.9.11

  • 25SulphatesClass
  • 25.9Sulphates of MnGroup
  • 25.9.11TorreyiteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1929Bauer, L. H., Berman, Harry (1929) Mooreite, a new mineral, and fluoborite from Sterling Hill, New Jersey. American Mineralogist, 14 (5) 165-172
  2. 1949Prewitt-Hopkins, Joan (1949) X-ray study of holdenite, mooreite and torreyite. American Mineralogist, 34 (7-8) 589-595
  3. 1951Palache, Charles; Berman, Harry; Frondel, Clifford (1951) The System of Mineralogy (7th ed.) Vol. 2 - Halides, Nitrates, Borates, Carbonates, Sulfates, Phosphates, Arsenates, Tungstates, Molybdates, Etc. John Wiley and Sons.
  4. 1979Dunn, Pete J., Peacor, Donald R., Sturman, B. Darko (1979) Lawsonbauerite, a new mineral from the Sterling Hill mine, New Jersey, and new data for torreyite. American Mineralogist, 64 (9-10) 949-952
  5. 1982Treiman, A. H., Peacor, D. R. (1982) The crystal structure of lawsonbauerite, (Mn,Mg)9Zn4(SO4)2(OH)22·8H2O, and its relation to mooreite. American Mineralogist, 67 (9-10) 1029-1034
