Trimerite

CaBe3Mn2+2(SiO4)3
IMA status
  • Approved
  • Grandfathered
IMA symbol
Tme
Discovered
1890
Also known as
  • Trimeriet

Where it forms, where it's found

Geological setting

In a magnetite-pyroxene-garnet skarn probably formed during late-stage hydrothermal activity.

Type locality
Harstigen Mine
  1. Pajsberg
  2. Persberg ore district
  3. Filipstad
  4. Värmland County
  5. Sweden

59.7853°, 14.3139°

6recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789106 – 7/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Colourless · pink · orange-red · yellow-red
Streak
White
Tenacity
brittle
Cleavage
Distinct/Good

Distinct on (001)

Fracture
Conchoidal
Density
3.474 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 83° · 2V calc = 88°
Refractive index
1.715 – 1.725
Surface relief
High
Principal indices
nα 1.715 · nβ 1.72 · nγ 1.725
Dispersion
r > v
Extinction
X perpendicular to {001}.
UV response
Yellow in LW-UV (365nm) and SW-UV (254nm).
Michel-Lévy diagramhighlighted lineδ = 0.0100
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]100 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation100 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#15
Cell parameters
a = 8.09 Å · b = 7.61 Å · c = 14.06 Å
Cell angles
β = 90 °
Ratio a:b:c
1 : 0.941 : 1.738
Z
4
Morphology

Crystals prismatic, pseudohexagonal by twinning to 12 mm; as crystal intergrowths.

Twinning

Triple twins with composition planes (110) and (1_10); in basal section, twin lamellae in three directions intersect at a 120 degree angle.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1215.999191.988
42.36%
25MnManganeseManganese254.938109.876
24.24%
14SiSiliconSilicon328.08584.255
18.59%
20CaCalciumCalcium140.07840.078
8.84%
4BeBerylliumBeryllium39.01227.036
5.97%
Total453.233100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Fe
  • Mg

Synonyms

  • Trimeriet

In other languages

French
trimérite
German
Trimerit
Italian
Trimerite

Classification

Strunz
10th ed.

9.AB.05

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.ABNesosilicates without additional anions; cations in [4] and greater coordinationGroup
  • 9.AB.05TrimeriteSpecies
Dana
8th ed.

51.02.01.01

  • 51Nesosilicates Insular Sio4 Groups OnlyClass
  • 51.02Insular SiO4 Groups Only with cations in [4] as well as >[4]Type
  • 51.02.01Trimerite groupGroup
  • 51.02.01.01TrimeriteSpecies
CIM

14.3.17

  • 14Silicates not Containing AluminumClass
  • 14.3Silicates of BeGroup
  • 14.3.17TrimeriteSpecies

Literature, links & citation

Citations
  1. 1891Flink, G. (1891) Ueber Pinakiolith und Trimerit, zwei neue Mineralien aus den Mangangruben Schwedens. Zeitschrift für Krystallographie, 18 (1). 361-376 doi:10.1524/zkri.1891.18.1.361DOI: 10.1524/zkri.1891.18.1.361
  2. 1891Brögger, W. C. (1891) Ueber die morphotropischen Beziehungen des Pinakiolith und des Trimerit zu verwandten Mineralien. Zeitschrift für Krystallographie, 18 (1). 377-385 doi:10.1524/zkri.1891.18.1.377DOI: 10.1524/zkri.1891.18.1.377
  3. 1926Aminoff, G. (1926) Zur Kristallographie des Trimerits. Geologiska Föreningen i Stockholm Förhandlingar, 48 (1) 19-43 doi:10.1080/11035892609445636DOI: 10.1080/11035892609445636
  4. 1927Foshag, W.F. (1927) New Mineral Names. American Mineralogist, 12 (10). 379-380
  5. 1977Klaska, K. H., Jarchow, O. (1977) Die Bestimmung der Kristallstruktur von Trimerit CaMn2(BeSiO4)3 und das Trimeritgesetz der Verzwillingung. Zeitschrift für Kristallographie, 145 (1). 46-65 doi:10.1524/zkri.1977.145.1-2.46 DOI: 10.1524/zkri.1977.145.1-2.46
