Tuhualite

NaFe2+Fe3+Si6O15
IMA status
  • Approved
  • Grandfathered
IMA symbol
Tuh
Discovered
1932
Also known as
  • Tuhualiet
  • Tuhualit

Where it forms, where it's found

Geological setting

In rhyolites.

Crystallization from magma quite impoverished in lime due to early fractionation of aegirine-hedenbergite, and perhaps aegirine-augite, in the intratelluric stage.

Type locality
Mayor Island (Tuhua)
  1. Bay of Plenty Region
  2. New Zealand

-37.2833°, 176.2500°

7recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103 – 4/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Dark blue to black · violet
Tenacity
very brittle
Cleavage
Distinct/Good

Three good on (001), (010), (100).

Density
2.89 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 70 – 91° · 2V calc = 68°
Refractive index
1.608 – 1.621
Surface relief
Moderate
Principal indices
nα 1.608 · nβ 1.612 · nγ 1.621
Pleochroism
Strong

X = colourless to pale lavender; Y = violet, lavender, Z = intense purplish-blue.

Dispersion
Strong, r < v.
Extinction
X = a; Y = b; Z = c.
Notes

Absorption: Z > Y >> X.

Michel-Lévy diagramhighlighted lineδ = 0.0130
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]130 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation130 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
Cmca
Cell parameters
a = 14.3285(8) Å · b = 17.2837(10) Å · c = 10.1202(6) Å
Ratio a:b:c
1 : 1.206 : 0.706
Z
4
Morphology

Prismatic. Forms include (100), (010), (001), (110), (111), (011), (021). As tabular crystals, flattened on [100] with pyramidal terminations. Also as irregular mosslike aggregates.

Type-locality form

"Relatively large grains."

Comment

Tuhualite revisited: new crystal data and structure refinements on specimens from two localities (Mayor Island).

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1515.999239.985
44.18%
14SiSiliconSilicon628.085168.510
31.03%
26FeIronIron255.845111.690
20.56%
11NaSodiumSodium122.99022.990
4.23%
Total543.175100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ti
  • Zr
  • Al
  • Mn
  • Mg
  • Ca
  • F
  • Cl
  • H2O

Synonyms

  • Tuhualiet
  • Tuhualit

In other languages

German
Tuhualith
Italian
Tuhualite

Classification

Strunz
10th ed.

9.DN.05

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DNInosilicates with 6-periodic double chainsGroup
  • 9.DN.05TuhualiteSpecies
Dana
8th ed.

66.03.04.01

  • 66Inosilicates Double-width, Unbranched Chains, (w=2)Class
  • 66.03Amphiboles - Ca-Na subgroupType
  • 66.03.04P=6 (Tahualite group)Group
  • 66.03.04.01TuhualiteSpecies
CIM

16.18.3

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.18Aluminosilicates of Fe and alkalisGroup
  • 16.18.3TuhualiteSpecies

Group, growth & confusion

In the same group
2 members

Literature, links & citation

Citations
  1. 1932Marshall, P. (1932) Notes on some volcanic rocks of the North Island of New Zealand. The New Zealand Journal of Science and Technology: 13: 198-202.
  2. 1933Foshag, W.F. (1933) New mineral names. American Mineralogist: 18: 179-180.
  3. 1937(1937) New mineral names; New data. American Mineralogist, 22 (11) 1131-1132
  4. 1937Marshall, P. (1937) The mineral tuhualite. Transactions and Proceedings of the New Zealand Institute, 66. 330-336
  5. 1956Fleischer, M. (1956) New mineral names. American Mineralogist, 41 (11-12). 958-960
