Tungstenite

WS2
IMA status
  • Approved
  • Grandfathered
IMA symbol
Tgt
Also known as
  • Tungsteniet
  • Tungstenite (of Wells and Butler)

Where it forms, where it's found

Geological setting

Replacing limestone

Replacing scheelite and in high temperature fumaroles

Type locality
Emma Mine
  1. Alta
  2. Little Cottonwood Mining District
  3. Salt Lake County
  4. Utah
  5. USA

40.5925°, -111.6311°

32recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Lead-gray
Tenacity
sectile
Cleavage
Distinct/Good

(0001)

Density
7.4 g/cm³

Optical

Pleochroism
Strong

very high

Optical colour
Pure white
Anisotropism
strong in colors of pink and deep blue
Tropism
Anisotropic
Reflectance R%
(24.4,53.4) 400, (22.6,48.0) 420, (20.8,48.6) 440, (19.9,40.5) 460, (19.3,39.0) 480, (18.8,37.8) 500, (18.5,36.8) 520, (18.2,36.0) 540, (18.0,35.3) 560, (17.8,35.0) 580, (17.8,34.9) 600, (17.9,34.9) 620, (18.0,34.8) 640, (18.1,34.7) 660, (18.0,34.5) 680, (17.9,34.2) 700
Reflected-light panel
19.1 %anisotropic · dual curve
Specimen sRGB 157, 109, 64
White reference100 % reflector under same lamp
R₁ R₂
Mode
Anisotropism
strong in colors of pink and deep blue
Reflected colour
Pure white

Crystallography

Crystal system
Trigonal
Space group
#86
Cell parameters
a = 3.158(1) Å · c = 18.49(1) Å
Z
3
Morphology

Massive, scaly to feathery aggregates.

Comment

On synthetic 3R polytype

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
74WTungstenTungsten1183.840183.840
74.14%
16SSulfurSulfur232.06064.120
25.86%
Total247.960100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Tungsteniet
  • Tungstenite (of Wells and Butler)

In other languages

German
Tungstenit
Italian
Tungstenite

Classification

Strunz
10th ed.

2.EA.30

  • 2Sulfides and SulfosaltsClass
  • 2.EMetal Sulfides, M: S <= 1:2Division
  • 2.EAM:S = 1:2 - With Cu, Ag, AuGroup
  • 2.EA.30TungsteniteSpecies
Dana
8th ed.

02.12.10.03

  • 02SulfidesClass
  • 02.12AmBnXp, with (m+n):p = 1:2Type
  • 02.12.10Molybdenite GroupGroup
  • 02.12.10.03TungsteniteSpecies
CIM

3.8.10

  • 3Sulphides, Selenides, Tellurides, Arsenides and Bismuthides (except the arsenides, antimonides and bismuthides of Cu, Ag and Au, which are included in Section 1)Class
  • 3.8Sulphides etc. of Cr, Mo, W an MnGroup
  • 3.8.10TungsteniteSpecies

Group, growth & confusion

In the same group
2 members

Literature, links & citation

Citations
  1. 1917Wells, R.C.; Butler, B.S. (1917) Tungstenite, a new mineral. Journal of the Washington Academy of Sciences, 7. 596-599
  2. 1918Gordon, S.G. (1918) New minerals. American Mineralogist: 3: 30-30.
  3. 1944Palache, Charles, Berman, Harry, Frondel, Clifford (1944) The System of Mineralogy (7th ed.) Vol. 1 - Elements, Sulfides, Sulfosalts, Oxides. John Wiley and Sons, New York.
  4. 1964Graeser, G. (1964) Über Funde der neuen rhomboedrischen MoS2-Modifikation (Molybdänit-3R) und von Tungstenit in den Alpen. Schweizerische mineralogische und petrographische Mitteilungen, 44. 121-128 doi:10.5169/SEALS-34329 DOI: 10.5169/SEALS-34329
  5. 1970Gait, R.I., Mandarino, J.A. (1970) Polytypes of tungstenite. The Canadian Mineralogist: 10: 729-731.
