Uralolite

Ca2Be4(PO4)3(OH)3 · 5H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Url
Discovered
1964
Also known as
  • Uraloliet
  • Uralolit

Where it forms, where it's found

Geological setting

In kaolin-hydromuscovite rocks.

Type locality
Boevskoe Be deposit (Boevka
  1. Severnoye)
  2. Kaslinsky District
  3. Chelyabinsk Oblast
  4. Russia

56.2456°, 61.3739°

10recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Silky · Vitreous
Transparency
Transparent · Translucent
Colour
Colourless · white · brown
Streak
White
Tenacity
brittle
Cleavage
Poor/Indistinct

(010), (100) indistinct

Fracture
Conchoidal
Density
2.05 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 66° · 2V calc = 70°
Refractive index
1.51 – 1.536
Surface relief
Moderate
Principal indices
nα 1.510 – 1.512 · nβ 1.525 – 1.526 · nγ 1.533 – 1.536
Dispersion
none
UV response
Uralolite from Dunton Quarry, Newry, Maine, USA fluoresces yellow-green. Uralolite from Ponte do Piauí claim, Taquaral, Brazil fluoresces medium cherry-red.
Michel-Lévy diagramhighlighted lineδ = 0.0235
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]235 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation235 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 6.550(1) Å · b = 16.005(3) Å · c = 15.969(4) Å
Cell angles
β = 101.64(2) °
Ratio a:b:c
1 : 2.444 : 2.438
Z
4
Morphology

Acicular to lath-like prismatic with elongation parallel to [100] and bladed development on (010). Striations parallel to [100]. Forms (021), (010), (001) and (101).

Twinning

Twinning reported from some localities (ex. Newry, Maine)

Type-locality form

Concretions composed of radiating fibrous spherulites of diameter 2-3 mm and in sheaf-like growths.

Comment

Space Group: P21/n.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2015.999319.980
59.01%
15PPhosphorusPhosphorus330.97492.922
17.14%
20CaCalciumCalcium240.07880.156
14.78%
4BeBerylliumBeryllium49.01236.048
6.65%
1HHydrogenHydrogen131.00813.104
2.42%
Total542.210100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Uraloliet
  • Uralolit

In other languages

German
Uralolith
Italian
Uralolite

Classification

Strunz
10th ed.

8.DA.15

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.DPhosphates, etc. with additional anions, with H2ODivision
  • 8.DAWith small (and occasionally larger) cationsGroup
  • 8.DA.15UraloliteSpecies
Dana
8th ed.

42.07.06.01

  • 42Hydrated Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 42.07(AB)2(XO4)Zq·xH2OType
  • 42.07.06Uralolite GroupGroup
  • 42.07.06.01UraloliteSpecies
CIM

19.3.7

  • 19PhosphatesClass
  • 19.3Phosphates of Be and MgGroup
  • 19.3.7UraloliteSpecies

Literature, links & citation

Citations
  1. 1964Fleischer, M. (1964) New Mineral Names. American Mineralogist, 49 (11-12) 1774-1778
  2. 1964Grigor'ev, N.A. (1964) Uralolite - a new mineral. Zapiski Vsesoyuznogo Mineralogicheskogo Obshchestva: 93(2): 156-162.
  3. 1978Dunn, Pete J., Gaines, Richard V. (1978) Uralolite from the Dunton Gem Mine, Newry, Maine: a Second Occurrence. The Mineralogical Record, 9 (2) Tucson. 99-100
  4. 1994Mereiter, Kurt, Niedermayr, Gerhard, Walter, Franz (1994) Uralolite, Ca2Be4(PO4)3(OH)3·5H2O: new data and crystal structure. European Journal of Mineralogy, 6 (6) 887-896 doi:10.1127/ejm/6/6/0887 DOI: 10.1127/ejm/6/6/0887
  5. 1995Jambor, John L., Puziewirz, Jacek, Roberts, Andrew C. (1995) New Mineral Names. American Mineralogist, 80. 1328-1333
