Uranotungstite

Ba(UO2)2W2O8(OH)2 · H2O
IMA status
  • Approved
IMA symbol
Utgs
Discovered
1984
IMA approved
1984
Also known as
  • IMA1984-005
  • Uranotungstiet

Where it forms, where it's found

Type locality
Krunkelbach Valley Uranium deposit
  1. Menzenschwand
  2. St Blasien
  3. Waldshut
  4. Freiburg Region
  5. Baden-Württemberg
  6. Germany

47.8389°, 8.0450°

6recorded occurrences
Source · OpenStreetMap

Radioactivity

Physical

Hardness
123456789102/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Yellow · orange · brown · blackish
Streak
Yellow
Cleavage
Perfect

(010)

Fracture
Irregular/Uneven
Density
>4.03 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 42° · 2V calc = 24°
Refractive index
1.682 – 1.855
Surface relief
High
Principal indices
nα 1.682 · nβ 1.845 · nγ 1.855
Pleochroism
Visible

X = nearly colorless, Y = Z = yellow

Dispersion
r > v moderate
Notes

X = b

Michel-Lévy diagramhighlighted lineδ = 0.1730
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1730 nm4th order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1730 nm
Order4th order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#15
Cell parameters
a = 6.318(5) Å · b = 7.388(9) Å · c = 13.71(4) Å
Cell angles
β = 99.04(13) °
Ratio a:b:c
1 : 1.169 : 2.170
Z
2
Morphology

Tabular, lath-shaped (pseudo-orthorhombic).

Twinning

Pervasive, parallel to the platey face (Kolitsch and Plášil, unpublished data).

Type-locality form

Spherulitic aggregates up to 0.3 mm in diameter.

Comment

Originally assumed to be orthorhombic, with a = 9.22, b = 13.81, c = 7.17 Å (Walenta, 1985).

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
92UUraniumUranium2238.029476.058
38.86%
74WTungstenTungsten2183.840367.680
30.01%
8OOxygenOxygen1515.999239.985
19.59%
56BaBariumBarium1137.327137.327
11.21%
1HHydrogenHydrogen41.0084.032
0.33%
Total1225.082100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1984-005
  • Uranotungstiet

In other languages

German
IMA 1984-005 · Uranotungstit
Italian
Uranotungstite

Classification

Strunz
10th ed.

7.HB.25

  • 7SulfatesClass
  • 7.HUranium and uranyl molybdates and wolframatesDivision
  • 7.HBWith U6+Group
  • 7.HB.25UranotungstiteSpecies
Dana
8th ed.

49.03.05.01

  • 49Hydrated Molybdates and TungstatesClass
  • 49.03Hydrated Molybdates and Tungstates Containing Hydroxyl or HalogenType
  • 49.03.05— unnamed intermediate level —Group
  • 49.03.05.01UranotungstiteSpecies
CIM

27.4.12

  • 27Sulphites, Chromates, Molybdates and TungstatesClass
  • 27.4TungstatesGroup
  • 27.4.12UranotungstiteSpecies

Literature, links & citation

Citations
  1. 1985Walenta, K. (1985) Uranotungstit, ein neues sekundäres Uranmineral aus dem Schwarzwald. TMPM Tschermaks Mineralogische und Petrographische Mitteilungen, 34 (1). 25-34 doi:10.1007/bf01082455DOI: 10.1007/bf01082455
  2. 1986Hawthorne, F.C., Bladh, K.W., Burke, E.A.J., Ercit, S., Grew, E.S., Grice, J.D., Puziewicz, J., Roberts, A.C., Schedler, R.A., Shigley, J.E. (1986) New mineral names. American Mineralogist: 71: 1543-1548.
  3. 2022Steciuk, Gwladys, Kolitsch, Uwe, Goliáš, Viktor, Škoda, Radek, Plášil, Jakub, Schmidt, Franz Xaver (2022) Uranotungstite, the only natural uranyl tungstate: Crystal structure revealed from 3D electron diffraction. American Mineralogist, 107 (9) 1709-1716 doi:10.2138/am-2022-8112DOI: 10.2138/am-2022-8112
  4. 2023(2023) Uranotungstite. Handbook of Mineralogy. Mineralogical Society of America
