Vandenbrandeite

Cu(UO2)(OH)4
IMA status
  • Approved
  • Grandfathered
IMA symbol
Vbd
Discovered
1932
Also known as
  • Uranolepidit
  • Uranolepidita
  • Uranolepidite
  • +1 more

Where it forms, where it's found

Geological setting

Oxide zone above a supergene copper deposit

Type locality
Kalongwe deposit
  1. Mutshatsha
  2. Lualaba
  3. DR Congo

-11.0164°, 25.2261°

11recorded occurrences
Source · OpenStreetMap

Radioactivity

Physical

Hardness
123456789104/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Blackish green to dark green with bluish green tint
Streak
Green
Tenacity
brittle
Cleavage
Perfect

On (001) perfect; distinct in the zone [001]; and, indistinct also in that zone.

Density
5.03 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 90° · 2V calc = 60 – 88°
Refractive index
1.765 – 1.8
Surface relief
High
Principal indices
nα 1.765 – 1.77 · nβ 1.78 – 1.792 · nγ 1.80
Birefringence
0.035
Pleochroism
Visible

X blue green, Z yellow green

Dispersion
none
UV response
Not fluorescent
Michel-Lévy diagramhighlighted lineδ = 0.0350
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]350 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation350 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
P-1
Cell parameters
a = 7.86 Å · b = 5.44 Å · c = 6.10 Å
Cell angles
α = 91.87 ° · β = 102.0 ° · γ = 89.62 °
Ratio a:b:c
1 : 0.692 : 0.776
Morphology

Somewhat bladed (001) crystals with acute habit, often in parallel aggregates; lathlike at times. Massive.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
92UUraniumUranium1238.029238.029
59.27%
8OOxygenOxygen615.99995.994
23.90%
29CuCopperCopper163.54663.546
15.82%
1HHydrogenHydrogen41.0084.032
1.01%
Total401.601100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Uranolepidit
  • Uranolepidita
  • Uranolepidite
  • Vandenbrandeiet

In other languages

German
Vandenbrandeit
Spanish
Uranolepidita · Vandenbrandeíta
Italian
Vandenbrandeite
Chinese
绿铀矿

Classification

Strunz
10th ed.

4.GB.45

  • 4OxidesClass
  • 4.GUranyl HydroxidesDivision
  • 4.GBWith additional cations (K, Ca, Ba, Pb, etc.); with mainly UO2(O,OH)5 pentagonal polyhedraGroup
  • 4.GB.45VandenbrandeiteSpecies
Dana
8th ed.

05.03.02.01

  • 05Oxides Containing Uranium or ThoriumClass
  • 05.03AXO4·xH2OType
  • 05.03.02— unnamed intermediate level —Group
  • 05.03.02.01VandenbrandeiteSpecies
CIM

7.16.9

  • 7Oxides and HydroxidesClass
  • 7.16Oxides of UGroup
  • 7.16.9VandenbrandeiteSpecies

Literature, links & citation

Citations
  1. 1932Schoep, A. (1932) La vandenbrandeite, un nouveau minéral uranifére. Annales du Musée du Congo Belge, Tervuren: 1(3): 24-31.
  2. 1933Foshag, W.F. (1933) New mineral names. American Mineralogist: 18: 179-180.
  3. 1933Thoreau, J. (1933) L'uranolepidite, nouveau mineral uranifere de Shinkolobwe (Katanga). Annales de la Societe Geologique de Belgique: 55,1931-1932: C3-C5. (as Uranolepidite)
  4. 1944Palache, Charles, Berman, Harry, Frondel, Clifford (1944) The System of Mineralogy (7th ed.) Vol. 1 - Elements, Sulfides, Sulfosalts, Oxides. John Wiley and Sons, New York.
  5. 1951Milne, I. H., Nuffield, E. W. (1951) Studies of radioactive compounds: I - Vandenbrandeite. American Mineralogist, 36 (5-6) 394-410
