Väyrynenite

BeMn2+(PO4)(OH)
IMA status
  • Approved
  • Grandfathered
IMA symbol
Väy
Discovered
1939
Also known as
  • Vaerynenite
  • Väyryneniet

Where it forms, where it's found

Geological setting

Granite pegmatite.

Alteration product of beryl and triphylite in complex granitic pegmatites.

Type locality
Viitaniemi pegmatite
  1. Eräjärvi area
  2. Orivesi
  3. Pirkanmaa
  4. Finland

61.5844°, 24.6772°

13recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Light pink to rose-red · salmon pink · pale gray · brown
Streak
White
Tenacity
brittle
Cleavage
Perfect

Perfect (010), good (100), fair (001).

Fracture
Irregular/Uneven
Density
3.22 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 46 – 55° · 2V calc = 51 – 57°
Refractive index
1.638 – 1.667
Surface relief
High
Principal indices
nα 1.638 – 1.64 · nβ 1.658 – 1.662 · nγ 1.664 – 1.667
Pleochroism
Visible

X= orangish Y= red Z= dark red

Dispersion
r > v moderate
Michel-Lévy diagramhighlighted lineδ = 0.0265
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]265 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation265 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#14
Cell parameters
a = 5.4044(6) Å · b = 14.5145(12) Å · c = 4.7052(6) Å
Cell angles
β = 102.798(9) °
Ratio a:b:c
1 : 2.686 : 0.871
Unit cell volume
359.91 ų
Z
4
Morphology

Often as fine grained aggregates. Euhedral crystals are rare. Short to long prismatic crystals parallel to [001]. Forms observed: (001), prisms (010) and (110). Prism faces are generally striated vertically

Comment

Huminicki and Hawthorne (2000)

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen515.99979.995
45.47%
25MnManganeseManganese154.93854.938
31.23%
15PPhosphorusPhosphorus130.97430.974
17.61%
4BeBerylliumBeryllium19.0129.012
5.12%
1HHydrogenHydrogen11.0081.008
0.57%
Total175.927100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • F

Synonyms

  • Vaerynenite
  • Väyryneniet

In other languages

German
Väyrynenit
Spanish
Väyrynenita
Italian
Väyrynenite
Japanese
ヴェイリネナイト

Classification

Strunz
10th ed.

8.BA.05

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.BPhosphates, etc., with additional anions, without H2ODivision
  • 8.BAWith small and medium-sized cationsGroup
  • 8.BA.05VäyryneniteSpecies
Dana
8th ed.

41.05.04.03

  • 41Anhydrous Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 41.05(AB)2(XO4)ZqType
  • 41.05.04Herderite GroupGroup
  • 41.05.04.03VäyryneniteSpecies
CIM

22.1.20

  • 22Phosphates, Arsenates or Vanadates with other AnionsClass
  • 22.1Phosphates, arsenates or vanadates with fluorideGroup
  • 22.1.20VäyryneniteSpecies

Literature, links & citation

Citations
  1. 1954Fleischer, M. (1954) New mineral names. American Mineralogist, 39 (9-10). 848-852
  2. 1954Volborth, A. (1954) Phospatminerale aus dem Lithiumpegmatit von Viitaniemi, Eräjärvi, Zentral-Finland. Ann. acad. Sci. Fennicae, Ser. A, III Geol.Geograf., 39:1-90.
  3. 1954Volborth, A., Stradner, E. (1954) Väyrynenit BeMn[PO4](OH), ein neues Mineral. Anzeiger der Österreichischen Akademie der Wissenschaften Mathematisch-Natur Wissenschaftliche Klasse: 92: 21-23.
  4. 1954Volborth, A. (1954) Väyryneniiti [BeMn[PO4](OH,F)]. Geologi(Finland): 6: 7. [Preliminary announcement]
  5. 1956Fleischer, M. (1956) New mineral names. American Mineralogist, 41 (3-4). 370-372
