Vitusite-(Ce)

Na3Ce(PO4)2
IMA status
  • Approved
IMA symbol
Vtu-Ce
Discovered
1976
IMA approved
1976
Also known as
  • IMA1976-055
  • Vitusiet-(Ce)

Where it forms, where it's found

Geological setting

Nepheline syenite pegmatite

Nepheline syenite pegmatite.

Type locality
Yubileinaya pegmatite
  1. Karnasurt Mountain
  2. Lovozersky District
  3. Murmansk Oblast
  4. Russia

67.8833°, 34.6333°

9recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Translucent
Colour
Pale pink · white · pale green · also yellow · gray to black
Streak
White
Tenacity
brittle
Cleavage
Distinct/Good

(001), (010), (100), but degree of development unstated

Density
3.60 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 30° · 2V calc = 22 – 32°
Refractive index
1.602 – 1.654
Surface relief
Moderate
Principal indices
nα 1.602 – 1.604 · nβ 1.647 – 1.650 · nγ 1.649 – 1.654
Birefringence
0.045
Pleochroism
Non-pleochroic
Dispersion
r > v
Extinction
XYZ = abc
Michel-Lévy diagramhighlighted lineδ = 0.0450
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]450 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation450 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
#29
Cell parameters
a = 5.342 Å · b = 18.680 Å · c = 14.062 Å
Ratio a:b:c
1 : 3.497 : 2.632
Z
8
Twinning

pseudohexagonal on (160) and (120)

Type-locality form

prismatic, to 5 mm granular, and in fine-grained aggregates.

Comment

Pc21b, Neues Jahrbuch MA 1980 137:42; a supercell 58.75

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
58CeCeriumCerium1140.116140.116
35.11%
8OOxygenOxygen815.999127.992
32.08%
11NaSodiumSodium322.99068.970
17.28%
15PPhosphorusPhosphorus230.97461.948
15.53%
Total399.026100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1976-055
  • Vitusiet-(Ce)

In other languages

German
IMA 1976-055 · Vitusit-(Ce)
Italian
Vitusite- · Vitusite-(Ce)
Chinese
磷铈钠石

Classification

Strunz
10th ed.

8.AC.35

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.APhosphates, etc. without additional anions, without H2ODivision
  • 8.ACWith medium-sized and large cationsGroup
  • 8.AC.35Vitusite-(Ce)Species
Dana
8th ed.

38.01.08.01

  • 38Anhydrous Normal Phosphates, Arsenates, and VanadatesClass
  • 38.01ABXO4Type
  • 38.01.08— unnamed intermediate level —Group
  • 38.01.08.01Vitusite-(Ce)Species
CIM

19.9.9

  • 19PhosphatesClass
  • 19.9Phosphates of rare earths and ScGroup
  • 19.9.9Vitusite-(Ce)Species

Literature, links & citation

Citations
  1. 1979Rønsbo, J.G., Khomyakov, A.P., Semenov, E.I., Voronkov, A.A., Garanin, V.K. (1979) Vitusite, a new phosphate of sodium and rare earths from the Lovozero alkaline massif, Kola and Ilímaussaq alkaline intrusion, South Greenland. Neues Jahrbuch für Mineralogie, Abhandlungen: 137: 42-53.
  2. 1980Fleischer, Michael, Cabri, Louis J., Chao, G. Y., Pabst, Adolf (1980) New Mineral Names. American Mineralogist, 65 (7-8) 808-814
  3. 1987Nickel, Ernest H., Mandarino, Joseph A. (1987) Procedures involving the IMA Commission on New Minerals and Mineral Names and guidelines on mineral nomenclature. American Mineralogist, 72 (9-10) 1031-1042
  4. 1990Horváth, László, Gault, Robert A. (1990) The Mineralogy of Mont Saint-Hilaire, Quebec. The Mineralogical Record, 21 (4) 281-359
  5. 1992Finch, Adrian A., Fletcher, James G. (1992) Vitusite — an apatite derivative structure. Mineralogical Magazine, 56 (383) 235-239 doi:10.1180/minmag.1992.056.383.10 DOI: 10.1180/minmag.1992.056.383.10
Cite this entry
@misc{mineral2026,
  author    = {Mineral Index editorial board},
  title     = {Vitusite-(Ce) — Mineral Index},
  year      = {2026},
  url       = {https://mineralindex.org/minerals/vitusite-ce-4193},
  note      = {Accessed 2026-05-11}
}
