Vyuntspakhkite-(Y)

Y(Al,Si)(SiO4)(OH,O)2
IMA status
  • Approved
IMA symbol
Vyu-Y
IMA approved
1982
Also known as
  • IMA1982-040
  • Vyuntspakhkiet-(Y)

Where it forms, where it's found

Geological setting

Amazonite pegmatite

Type locality
Ploskaya Mountain
  1. Western Keivy Massif
  2. Keivy Mountains
  3. Lovozersky District
  4. Murmansk Oblast
  5. Russia

67.6333°, 36.7000°

4recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106 – 7/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Colourless to tan
Tenacity
brittle
Cleavage
None Observed
Density
4.02 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 68° · 2V calc = 66°
Refractive index
1.68 – 1.72
Surface relief
High
Principal indices
nα 1.680 · nβ 1.692 · nγ 1.720
Dispersion
r < v weak
Michel-Lévy diagramhighlighted lineδ = 0.0400
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]400 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation400 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 5.7551(11) Å · b = 14.752(3) Å · c = 15.906(4) Å
Cell angles
β = 96.046(4) °
Ratio a:b:c
1 : 2.563 : 2.764
Z
2
Morphology

Microinclusions in yttrofluorite.

Type-locality form

0.5- 0.7 mm large , slender, prismatic crystals in small cavities within violet fine grained fluorite.

Comment

Space group: P21/n, Cell parameters from Yakbovich & Steele (2009)

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen815.999127.992
42.37%
39YYttriumYttrium188.90688.906
29.43%
14SiSiliconSilicon228.08556.170
18.60%
13AlAluminiumAluminium126.98226.982
8.93%
1HHydrogenHydrogen21.0082.016
0.67%
Total302.066100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1982-040
  • Vyuntspakhkiet-(Y)

In other languages

German
IMA 1982-040 · Vyuntspakhkit-(Y)
Italian
Vyuntspakhkite- · Vyuntspakhkite-(Y)

Classification

Strunz
10th ed.

9.BG.40

  • 9SilicatesClass
  • 9.BSorosilicatesDivision
  • 9.BGSorosilicates with mixed SiO4 and Si2O7 groups; cations in octahedral [6] and greater coordinationGroup
  • 9.BG.40Vyuntspakhkite-(Y)Species
Dana
8th ed.

61.01.18.01

  • 61Cyclosilicates Six-membered RingsClass
  • 61.01Six-Membered Rings with [Si6O18] rings; possible (OH) and Al substitutionType
  • 61.01.18— unnamed intermediate level —Group
  • 61.01.18.01Vyuntspakhkite-(Y)Species
CIM

16.13.1

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.13Aluminosilicates of the rare earthsGroup
  • 16.13.1Vyuntspakhkite-(Y)Species

Literature, links & citation

Citations
  1. 1983Voloshin, A.V., Pakhomovsky, Ya.A., Menshikov, Yu P., Povarennykh, A.S. and Rogachev, D.L. (1983) Vyuntspakhite Y4Al2AlSi5O18(OH)5 a new yttrium-aluminum silicate from amazonite pegmatites of the Kola Peninsula. Mineralogicheskii Zhurnal: 5(4): 89-94.
  2. 1983Voloshin, A. V., Pakhomovsky, Ya. A.,Menshikov,Yu P.,Povarennykh, A.S. and Rogachev, D.L. (1983) Vyuntspakhite Y4Al2AlSi5O18(OH)5 a new yttrium-aluminum silicate from amazonite pegmatites of the Kola Peninsula. Mineralogicheskii Zhurnal (1983): 5(4): 89-94.
  3. 1984Dunn, Pete J.; Cabri, Louis J.; Ferraiolo, James A.; Grice, Joel Do.; Jambor, John L.; Mueller, Wolfgang; Shigley, James E.; Puziewicz, Jacek; Vanko, David A. (1984) New mineral names. American Mineralogist, 69 (11-12). 1190-1196
  4. 1986Voloshin, A.V., Pakhomovskii, Ya.A. (1986) Minerals and mineral formation evolution in amazonite pegmatites of Kola peninsula. Leningrad, Nauka: pp. 168. (in Russian)
  5. 1998Pekov, Igor V. (1998) Minerals first discovered on the territory of the former Soviet Union. Ocean Pictures, Moscow. 369pp.
