Weeksite

(K)2(UO2)2(Si5O13) · 4H2O
IMA status
  • Approved
IMA symbol
Wks
Discovered
1960
Also known as
  • Weeksiet

Where it forms, where it's found

Geological setting

In opal veinlets and as replacements of pebbles in tuffaceous conglomerate.

it is formed as a product of the relatively mild hydrothermal transformation of the parental rocks.

Type locality
Autunite No. 8 claim
  1. Topaz Mountain
  2. Thomas Range
  3. Juab County
  4. Utah
  5. USA

39.6972°, -113.0778°

40recorded occurrences
Source · OpenStreetMap

Radioactivity

Physical

Hardness
123456789101 – 2/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Yellow
Cleavage
Distinct/Good

Two good prismatic cleavages noted.

Density
4.1 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 60° · 2V calc = 66°
Refractive index
1.596 – 1.606
Surface relief
Moderate
Principal indices
nα 1.596 · nβ 1.603 · nγ 1.606
Pleochroism
Strong

X = colorless, Y = pale yellow-green, Z = yellow-green.

Dispersion
r < v weak
Michel-Lévy diagramhighlighted lineδ = 0.0100
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]100 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation100 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 14.2183(8) Å · b = 14.1794(6) Å · c = 9.6229(6) Å
Cell angles
β = 111.445(7) °
Ratio a:b:c
1 : 0.997 : 0.677
Z
1
Twinning

By two-fold rotation around [40_1]. The correct model (reticular twin, diffraction type II; Petříček et al. 2016) involves a two-fold axis operation (or mirror, as an alternative co-set) in (101), which leads to an orthorhombic lattice of four-times larger volume of the unit-cell.

Type-locality form

Yellow radiating fibrous clusters

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
92UUraniumUranium2238.029476.058
45.83%
8OOxygenOxygen2115.999335.979
32.34%
14SiSiliconSilicon528.085140.425
13.52%
19KPotassiumPotassium239.09878.196
7.53%
1HHydrogenHydrogen81.0088.064
0.78%
Total1038.722100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Al
  • Fe
  • Ca
  • Ba
  • Na
  • C

Synonyms

  • Weeksiet

In other languages

German
Weeksit
Spanish
Weeksita
Italian
weeksite
Japanese
ウィークス石
Chinese
多硅钾铀矿

Classification

Strunz
10th ed.

9.AK.30

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.AKUranyl neso- and polysilicatesGroup
  • 9.AK.30WeeksiteSpecies
Dana
8th ed.

53.03.02.01

  • 53Nesosilicates Insular Sio4 Groups and Other Anions or Complex CationsClass
  • 53.03Insular SiO4 Groups and Other Anions of Complex Cations with (UO2)Type
  • 53.03.02Weeksite groupGroup
  • 53.03.02.01WeeksiteSpecies
CIM

14.16.5

  • 14Silicates not Containing AluminumClass
  • 14.16Silicates of UGroup
  • 14.16.5WeeksiteSpecies

Literature, links & citation

Citations
  1. 1960Outerbridge, W. F., Staatz, M. H., Meyrowitz, R., Pommer, A. M. (1960) Weeksite, a new uranium silicate from the Thomas Range, Juab County, Utah. American Mineralogist, 45 (1-2) 39-52
  2. 1961Fleischer, Michael (1961) New mineral names. American Mineralogist, 46 (3-4). 464-468
  3. 1962(1962) International Mineralogical Association: Commission on New Minerals and Mineral Names. Mineralogical Magazine and Journal of the Mineralogical Society, 33 (258) 260-263 doi:10.1180/minmag.1962.033.258.09 DOI: 10.1180/minmag.1962.033.258.09
  4. 1973Stohl, F.V., Smith, D.K. (1973) Crystal structures of boltwoodite and weeksite. GSA Annual Meeting Program: 5: 824.
  5. 1977Deliens, Michel (1977) Présence de weeksite aux Bois Noirs, massif du Forez (Loire) Bulletin de Minéralogie, 100 (5) 275 doi:10.3406/bulmi.1977.7149DOI: 10.3406/bulmi.1977.7149
