Weissbergite

TlSbS2
IMA status
  • Approved
IMA symbol
Wsb
Discovered
1975
IMA approved
1975
Also known as
  • IMA1975-040
  • Weissbergiet

Where it forms, where it's found

Geological setting

Carlin type hydrothermal deposit.

Type locality
Carlin Gold mine
  1. Elko
  2. Lynn Mining District
  3. Eureka County
  4. Nevada
  5. USA

40.9117°, -116.3239°

8recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789101.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Steel-gray
Streak
Dark gray
Tenacity
brittle
Cleavage
Perfect

Four different cleavages: one perfect, two very good, one good.

Density
5.79 g/cm³

Optical

Pleochroism
Weak
Optical colour
creamy white
Anisotropism
Strong, blue-green, blue-black, orange-brown, gray
Tropism
Anisotropic
Reflectance R%
(36.0,38.4) 470, (35.0,36.8) 546, (34.5,35.8) 589, (32.1,33.8) 650
Reflected-light panel
34.4 %anisotropic · dual curve
Specimen sRGB 207, 148, 83
White reference100 % reflector under same lamp
R₁ R₂
Mode
Anisotropism
Strong, blue-green, blue-black, orange-brown, gray
Reflected colour
creamy white

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 6.123 Å · b = 6.293 Å · c = 11.838 Å
Cell angles
α = 101.34 ° · β = 98.39 ° · γ = 103.21 °
Ratio a:b:c
1 : 1.028 : 1.933
Z
4
Morphology

Frequently anhedral granular.

Type-locality form

Irregular, broken or fractured grains, 0.5 mm in maximum dimension.

Comment

Originally assumed to have space group P1 (no. 1).

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
81TlThalliumThallium1204.380204.380
52.37%
51SbAntimonyAntimony1121.760121.760
31.20%
16SSulfurSulfur232.06064.120
16.43%
Total390.260100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1975-040
  • Weissbergiet

In other languages

German
IMA 1975-040 · Weissbergit
Italian
Weissbergite
Chinese
维硫锑铊矿

Classification

Strunz
10th ed.

2.HD.05

  • 2Sulfides and SulfosaltsClass
  • 2.HSulfosalts of SnS archetypeDivision
  • 2.HDWith TlGroup
  • 2.HD.05WeissbergiteSpecies
Dana
8th ed.

03.07.07.01

  • 03SulfosaltsClass
  • 03.07ø = 2Type
  • 03.07.07— unnamed intermediate level —Group
  • 03.07.07.01WeissbergiteSpecies
CIM

5.5.13

  • 5Sulphosalts - Sulpharsenites and Sulphobismuthites (those containing Sn, Ge,or V are in Section 6)Class
  • 5.5Sulpharsenites etc. of TlGroup
  • 5.5.13WeissbergiteSpecies

Literature, links & citation

Citations
  1. 1978Dickson, Frank W., Radtke, Arthur S. (1978) Weissbergite, TlSbS2, a new mineral from the Carlin gold deposit, Nevada. American Mineralogist, 63 (7-8) 720-724
  2. 1983Rey, N., Jumas, J.C., Olivier-Fourcade, J., Philippot, E. (1983): Sur les composés III-V-VI: Etude structurale du disulfure d’antimoine et de thallium. Acta Crystallographica, 39, 971-974.
  3. 1993Rieck, Branko (1993) Famous Mineral Localities: Allchar, Macedonia. The Mineralogical Record, 24 (6) 437-449
  4. 2005(2005) Weissbergite. Handbook of Mineralogy. Mineralogical Society of America
  5. 2011Kharbish, S. (2011) Raman spectroscopic investigations of some Tl-sulfosalt minerals containing pyramidal (As,Sb)S3 groups. American Mineralogist, 96 (4) 609-616 doi:10.2138/am.2011.3653DOI: 10.2138/am.2011.3653
