Zabuyelite

Li2(CO3)
IMA status
  • Approved
IMA symbol
Zab
Discovered
1985
IMA approved
1985
Also known as
  • Diomignite
  • IMA1985-018

Where it forms, where it's found

Geological setting

Periphery of a Li-rich salt lake.

Type locality
Chabyer Caka (Chabyer Co
  1. Zhabuye Chaka
  2. Zhabuye Cuo
  3. Zabuye salt lake)
  4. Zhongba Co.
  5. Xigazê Prefecture (Rikaze Prefecture
  6. Shigatse Prefecture)
  7. Tibet
  8. China

31.3722°, 84.0531°

11recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Transparent
Colour
Colourless
Streak
White
Tenacity
brittle
Cleavage
Perfect

Perfect (100) and moderate (011).

Density
2.09 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 25° · 2V calc = 22°
Refractive index
1.4285 – 1.5743
Surface relief
Moderate
Principal indices
nα 1.4285 · nβ 1.5672 · nγ 1.5743
Dispersion
none
Extinction
Y = b, Z ∧ c = 10°.
UV response
Not fluorescent.
Michel-Lévy diagramhighlighted lineδ = 0.1458
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1458 nm3rd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1458 nm
Order3rd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/c
Cell parameters
a = 8.361(1) Å · b = 4.976(2) Å · c = 6.193(3) Å
Cell angles
β = 114.69(3) °
Ratio a:b:c
1 : 0.595 : 0.741
Z
4
Morphology

Pyramidal-terminated prismatic crystals.

Twinning

(100)

Type-locality form

Crystals 1.5 to 20 µm long embedded in halite in rock-salt layers, and as doubly terminated crystals in precipitates. Typically 0.1 to 0.5 mm long, 0.03 to 0.15 mm wide, and 0.02 to 0.5 mm thick; crystals up to 1.2 mm long have been observed.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen315.99947.997
64.96%
3LiLithiumLithium26.94013.880
18.78%
6CCarbonCarbon112.01112.011
16.26%
Total73.888100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Diomignite
  • IMA1985-018

In other languages

French
zabuyelite
German
IMA 1985-018 · Zabuyelit
Spanish
diomignita · Zabuyelita
Italian
Zabuyelite
Chinese
扎布耶石

Classification

Strunz
10th ed.

5.AA.05

  • 5CarbonatesClass
  • 5.ACarbonates without additional anions, without H2ODivision
  • 5.AAAlkali carbonatesGroup
  • 5.AA.05ZabuyeliteSpecies
Dana
8th ed.

14.01.06.02

  • 14Anhydrous Normal CarbonatesClass
  • 14.01A(XO3)Type
  • 14.01.06Natrite GroupGroup
  • 14.01.06.02ZabuyeliteSpecies
CIM

11.1.1

  • 11CarbonatesClass
  • 11.1Carbonates of the alkali metals and ammoniumGroup
  • 11.1.1ZabuyeliteSpecies

Literature, links & citation

Citations
  1. 1892Mallard, M.E. (1892): Sur la forme cristalline du carbonate de lithine. Bulletin de la Société Française de Minéralogie et de Cristallographie, 15, 21-26.
  2. 1957Zemann, J. (1957) Die Kristallstruktur von Li2CO3. Acta Crystallographica, 10 (10) 664-666 doi:10.1107/s0365110x57002297DOI: 10.1107/s0365110x57002297
  3. 1979Effenberger, H., Zemann, J. (1979) Verfeinerung der Kristallstruktur des Lithiumkarbonates, Li2CO3. Zeitschrift für Kristallographie, 150 (1). 133-138 doi:10.1524/zkri.1979.150.1-4.133 DOI: 10.1524/zkri.1979.150.1-4.133
  4. 1987Zheng Mianping and Liu Wengao (1987): A new mineral - Zabuyelite. Acta Mineralogica Sinica, 7(3), 221-226. (in Chinese with English abstract)
  5. 1990Jambor, John L., Grew, Edward S. (1990) New Mineral Names. American Mineralogist, 75 (1-2) 240-246
