Zaherite

Al12(SO4)5(OH)26 · 20H2O
IMA status
  • Approved
IMA symbol
Zah
Discovered
1977
IMA approved
1977
Also known as
  • IMA1977-002

Where it forms, where it's found

Geological setting

Kaolinite-boehmite rock.

Type locality
Salt Range
  1. Punjab Province
  2. Pakistan
5recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Pearly · earthy
Transparency
Translucent
Colour
White to blue-green
Cleavage
Very Good

In one direction

Density
2.007 g/cm³

Optical

Optical type
Biaxial (+) · 2V calc = 38°
Refractive index
1.498 – 1.499
Surface relief
Low
Principal indices
nα 1.498 · nβ 1.4981 · nγ 1.499
Birefringence
Extremely low
Dispersion
very weak
Michel-Lévy diagramhighlighted lineδ = 0.0010
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]10 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation10 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Cell parameters
a = 18.47 Å · b = 19.45 Å · c = 3.77 Å
Cell angles
α = 95.24 ° · β = 91.48 ° · γ = 80.24 °
Ratio a:b:c
1 : 1.053 : 0.204
Type-locality form

Veinlets (up to 1 cm across) that cut massive kaolinite-boehmite rock. Densely packed aggregates of extremely small grains.

Comment

Space group P1 or P-1.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen6615.9991055.934
65.73%
13AlAluminiumAluminium1226.982323.784
20.15%
16SSulfurSulfur532.060160.300
9.98%
1HHydrogenHydrogen661.00866.528
4.14%
Total1606.546100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1977-002

In other languages

German
IMA 1977-002 · Zaherit
Italian
Zaherite
Chinese
水羟铝矾
Arabic
ظاهريت
Hindi
ज़ाहिरइट

Classification

Strunz
10th ed.

7.DE.65

  • 7SulfatesClass
  • 7.DSulfates (selenates, etc.) with additional anions, with H2ODivision
  • 7.DEWith only medium-sized cations; unclassifiedGroup
  • 7.DE.65ZaheriteSpecies
Dana
8th ed.

31.10.03.01

  • 31Hydrated Sulfates Containing Hydroxyl or HalogenClass
  • 31.10MiscellaneousType
  • 31.10.03— unnamed intermediate level —Group
  • 31.10.03.01ZaheriteSpecies
CIM

25.6.11

  • 25SulphatesClass
  • 25.6Sulphates of Al and TlGroup
  • 25.6.11ZaheriteSpecies

Literature, links & citation

Citations
  1. 1969Zaher, M.A. (1969) A study of the clays of the Salt Range and Kala-Chitta Hills, West Pakistan. Thesis, Michigan Technological University: 148 pp.
  2. 1977Routsala, A. P., Babcock, L. L. (1977) Zaherite, a new hydrated aluminum sulfate. American Mineralogist, 62 (11-12) 1125-1128
  3. 1984Beukes, G. J., Schoch, A. E., de Bruiyn, H., Van der Westhuizen, W. A., Bok, L. D. C. (1984) A new occurrence of the hydrated aluminium sulphate zaherite, from Pofadder, South Africa. Mineralogical Magazine, 48 (346) 131-135 doi:10.1180/minmag.1984.048.346.18 DOI: 10.1180/minmag.1984.048.346.18
  4. 1985Schoch, A. E., Beukes, G. J., Praekelt, H. E. (1985) A natroalunite - zaherite - hotsonite paragenesis from Pofadder, Bushmanland, South Africa. The Canadian Mineralogist, 23 (1) 29-34
  5. 1985De Bruiyn, H., Schoch, A. E., Beukes, G. J., Bok, L. D. C., Van Der Westhuizen, W. A. (1985) Note on cell parameters of zaherite. Mineralogical Magazine, 49 (350) 145-146 doi:10.1180/minmag.1985.049.350.26 DOI: 10.1180/minmag.1985.049.350.26
