Zincospiroffite

Zn2Te3O8
IMA status
  • Approved
IMA symbol
Zspf
IMA approved
2002
Also known as
  • IMA2002-047
  • Zincospiroffiet
  • Zinkospiroffit

Where it forms, where it's found

Geological setting

Secondary co-oxidation product in gold-bearing ore veins.

Type locality
Zhongshangou Mine
  1. Dongping Au-Te ore field
  2. Shuiquangou Complex
  3. Chongli District
  4. Zhangjiakou
  5. Hebei
  6. China

40.9036°, 115.1028°

7recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Grey
Streak
Dark green
Tenacity
brittle
Cleavage
None Observed
Fracture
Irregular/Uneven
Density
5.57 g/cm³

Optical

Pleochroism
Weak
Optical colour
Gray
Anisotropism
Weak
Bireflectance
Weak
Internal reflections
None
Tropism
Anisotropic
Reflectance R%
(22.3,29.7) 400, (12.7,16.1) 420, (6.9,8.6) 440, (6.7,7.3) 460, (7.0,7.5) 470, (7.4,7.7) 480, (7.6,7.9) 500, (7.6,8.1) 520, (7.4,7.8) 540, (7.1,7.3) 546, (6.9,6.9) 560, (6.4,6.4) 580, (6.1,6.2) 589, (5.9,6.0) 600, (5.4,5.6) 620, (4.8,5.3) 640, (4.4,5.0) 650, (4.1,4.6) 660, (3.6,4.2) 680, (3.1,3.7) 700
Reflected-light panel
7.2 %anisotropic · dual curve
Specimen sRGB 88, 70, 38
White reference100 % reflector under same lamp
R₁ R₂
Mode
Bireflectance
Weak
Anisotropism
Weak
Reflected colour
Gray
Internal reflections
None

Crystallography

Crystal system
Monoclinic
Space group
C2/c
Cell parameters
a = 12.72(4) Å · b = 5.15(1) Å · c = 11.82(3) Å
Cell angles
β = 99.2(3) °
Ratio a:b:c
1 : 0.405 : 0.929
Z
4
Morphology

micrometric aggregates to 0.35 mm

Type-locality form

As micrometric films coating <M>calaverite</M> or in irregular aggregates replacing <M>calaverite</M>.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
52TeTelluriumTellurium3127.600382.800
59.67%
30ZnZincZinc265.380130.760
20.38%
8OOxygenOxygen815.999127.992
19.95%
Total641.552100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2002-047
  • Zincospiroffiet
  • Zinkospiroffit

In other languages

German
IMA 2002-047 · Zincospiroffit
Italian
Zincospiroffite

Classification

Strunz
10th ed.

4.JK.10

  • 4OxidesClass
  • 4.JArsenites, antimonites, bismuthites, sulfites, selenites, tellurites; iodatesDivision
  • 4.JKTellurites without additional anions, without H2OGroup
  • 4.JK.10ZincospiroffiteSpecies

Group, growth & confusion

In the same group
1 members

Literature, links & citation

Citations
  1. 1966Hanke, K. (1966) Die Kristallstruktur von Zn2Te3O8. Die Naturwissenschaften, 53 (11). 273 doi:10.1007/bf00621643DOI: 10.1007/bf00621643
  2. 2004Zhang, P.H., Zhu, J.C., Zhao, Z.H., Gu, X.P., Lin, J.F. (2004) Zincospiroffite, a new tellurite mineral species from the Zhongshangou gold deposit, Hebei Province, People's Republic of China. The Canadian Mineralogist, 42, 763-768.
  3. 2013(2013) Zincospiroffite. Handbook of Mineralogy. Mineralogical Society of America
