Zugshunstite-(Ce)

CeAl(SO4)2(C2O4) · 12H2O
IMA status
  • Approved
IMA symbol
Zug-Ce
IMA approved
1996
Also known as
  • IMA1996-055
  • Zugshunstiet-(Ce)

Where it forms, where it's found

Geological setting

Cave

Type locality
Alum Cave Bluff
  1. Sevier County
  2. Tennessee
  3. USA

35.6388°, -83.4460°

2recorded occurrences
Source · OpenStreetMap

Physical

Lustre
Vitreous
Transparency
Translucent
Colour
Light pink (incandescent light) · pale blue (fluorescent light)
Streak
White
Tenacity
brittle
Cleavage
Poor/Indistinct

poor on (010)

Fracture
Irregular/Uneven
Density
2.121 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 85° · 2V calc = 82°
Refractive index
1.455 – 1.528
Surface relief
Low
Principal indices
nα 1.455 · nβ 1.485 · nγ 1.528
Dispersion
medium
UV response
None observed
Michel-Lévy diagramhighlighted lineδ = 0.0730
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]730 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation730 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/c
Cell parameters
a = 8.718(1) Å · b = 18.313(2) Å · c = 13.128(2) Å
Cell angles
β = 93.90(1) °
Ratio a:b:c
1 : 2.101 : 1.506
Z
4
Type-locality form

Equant, stubby individual crystals up to 1.0 mm in diameter, and in subparallel aggregates up to 1.5 mm in diameter

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2415.999383.976
57.88%
58CeCeriumCerium1140.116140.116
21.12%
16SSulfurSulfur232.06064.120
9.66%
13AlAluminiumAluminium126.98226.982
4.07%
1HHydrogenHydrogen241.00824.192
3.65%
6CCarbonCarbon212.01124.022
3.62%
Total663.408100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1996-055
  • Zugshunstiet-(Ce)

In other languages

German
IMA 1996-055 · Zugshunstit- · Zugshunstit-(Ce)
Italian
Zugshunstite- · Zugshunstite-(Ce)

Classification

Strunz
10th ed.

10.AB.75

  • 10Organic CompoundsClass
  • 10.ASalts of organic acidsDivision
  • 10.ABOxalatesGroup
  • 10.AB.75Zugshunstite-(Ce)Species

Literature, links & citation

Citations
  1. 2001Jambor, J.L., Roberts, A.C. (2001) New mineral names. American Mineralogist, 86. 1534-1537
  2. 2001Rouse, R. C., Peacor, D. R., Essene, E. J., Coskren, T. D., Lauf, R. J. (2001) The new minerals levinsonite-(Y) [(Y, Nd,Ce)Al(SO4)2(C2O4) · 12H2O] and zugshunstite-(Ce) [(Ce,Nd,La)Al(SO4)2(C2O4) · 12H2O]: Coexisting oxalates with different structures and differentiation of LREE and HREE. Geochimica et Cosmochimica Acta, 65 (7) 1101-1115 doi:10.1016/s0016-7037(00)00568-8DOI: 10.1016/s0016-7037(00)00568-8
  3. 2001Mandarino, Joseph A. (2001) New minerals. The Canadian Mineralogist, 39 (5) 1473-1502 doi:10.2113/gscanmin.39.5.1473 DOI: 10.2113/gscanmin.39.5.1473
  4. 2005(2005) Zugshunstite-(Ce). Handbook of Mineralogy. Mineralogical Society of America
  5. 2010Echigo, T., Kimata, M. (2010) Crystal Chemistry and Genesis of Organic Minerals: a Review of Oxalate and Polycyclic Aromatic Hydrocarbon Minerals. The Canadian Mineralogist, 48 (6) 1329-1357 doi:10.3749/canmin.48.5.1329DOI: 10.3749/canmin.48.5.1329
