Zunyite

Al13Si5O20(OH,F)18Cl
IMA status
  • Approved
  • Grandfathered
IMA symbol
Zun

Where it forms, where it's found

Type locality
Zuni Mine
  1. Anvil Mountain
  2. San Juan County
  3. Colorado
  4. USA

37.8370°, -107.7039°

80recorded occurrences
Source · OpenStreetMap

Varieties

Physical

Hardness
123456789107/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Colourless · grey · white · flesh-red
Streak
White
Tenacity
brittle
Cleavage
Distinct/Good

(111)

Density
2.88 g/cm³

Optical

Optical type
Isotropic
Surface relief
Moderate
Principal indices
n 1.562 – 1.600
Pleochroism
Non-pleochroic
UV response
May fluoresce red.
Isotropy testPPL ↔ XPL diagnostic
PPL intrinsic colour; no change on stage rotation
XPL extinct at every orientation
Single index
n = 1.581

Crystallography

Crystal system
Isometric
Space group
#208
Cell parameters
a = 13.925 Å
Z
4
Morphology

Commonly as modified tetrahedral crystals.

Twinning

Contact and penetration on (111).

Type-locality form

Well formed tetrahedral crystals in sulphide. Tiny crystals are clear, larger crystals, reaching 3 mm, contain black inclusions.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen3815.999607.962
40.67%
13AlAluminiumAluminium1326.982350.766
23.47%
9FFluorineFluorine1818.998341.964
22.88%
14SiSiliconSilicon528.085140.425
9.40%
17ClChlorineChlorine135.45035.450
2.37%
1HHydrogenHydrogen181.00818.144
1.21%
Total1494.711100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

In other languages

French
Zunyite
German
Zunyit
Spanish
Zuñiíta
Italian
Zunyite
Japanese
ズニ石

Classification

Strunz
10th ed.

9.BJ.55

  • 9SilicatesClass
  • 9.BSorosilicatesDivision
  • 9.BJSorosilicates with Si3O10, Si4O11, etc. anions; cations in octahedral [6] and greater coordinationGroup
  • 9.BJ.55ZunyiteSpecies
Dana
8th ed.

57.03.01.01

  • 57Sorosilicates Si3o10 Groups and Larger Noncyclic GroupsClass
  • 57.03Insular Si3O10 and Larger Noncyclic Groups with [Si5O16] groupsType
  • 57.03.01— unnamed intermediate level —Group
  • 57.03.01.01ZunyiteSpecies
CIM

17.3.2

  • 17Silicates Containing other AnionsClass
  • 17.3Silicates with chloride (including aluminosilicates)Group
  • 17.3.2ZunyiteSpecies

Literature, links & citation

Citations
  1. 1885Hillebrand, W.F. (1885) On zunyite and guitermanite, two new minerals from Colorado. Proceedings of the Colorado Scientific Society: 1: 124-132.
  2. 1921Albis, M. (1921) Indici di rifrazione della cancrinite, della zunyite e della organite: Rend. R. Accad. Linc ei, Cl. Sci. Fis., Roma: (5)30: 472. Min. Abstr. II, 22.
  3. 1926Gossner, B., Mussgnug, F. (1926) Die chemische Zusammensetzung von Zunyite (The chemical composition of Zunyite). Centralblatt für Mineralogie, Abt A: 149-155.
  4. 1927Gossner, B. (1927) Rontgenographische Untersuchungen am Zunyite (X-ray examinations on Zunyite). Neues Jahrbuch für Mineralogie, Abt A., Beil.-Bd. 55A: 319-332.
  5. 1930Spencer, L. (1930) Note on the crystallography of zunyite. Mineralogical Magazine: 22: 217-220.
