Zussmanite

K(Fe,Mg,Mn)13(Si,Al)18O42(OH)14
IMA status
  • Approved
IMA symbol
Zus
Discovered
1964
IMA approved
1964
Also known as
  • IMA1964-018
  • Zussmaniet

Where it forms, where it's found

Geological setting

Blue-schist facies metamorphism.

Type locality
Laytonville Quarry
  1. Laytonville
  2. Coastal Range
  3. California
  4. USA

39.6181°, -123.4631°

7recorded occurrences
Source · OpenStreetMap

Physical

Transparency
Transparent
Colour
Light to medium green
Tenacity
flexible
Cleavage
Perfect

(0001)

Fracture
Micaceous
Density
3.146 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.623 – 1.643
Surface relief
Moderate
Principal indices
nω 1.643 · nε 1.623
Birefringence
0.020
Pleochroism
Weak

O = pale green, e = colourless

Extinction
parallel
UV response
Not fluorescent in UV
Michel-Lévy diagramhighlighted lineδ = 0.0200
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]200 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation200 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
#78
Cell parameters
a = 11.66 Å · c = 28.69 Å
Z
3
Morphology

Platy granular

Type-locality form

Green grains and bands of grains in black matrix

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen5615.999895.944
24.24%
26FeIronIron1355.845725.985
19.64%
25MnManganeseManganese1354.938714.194
19.32%
14SiSiliconSilicon1828.085505.530
13.67%
13AlAluminiumAluminium1826.982485.676
13.14%
12MgMagnesiumMagnesium1324.305315.965
8.55%
19KPotassiumPotassium139.09839.098
1.06%
1HHydrogenHydrogen141.00814.112
0.38%
Total3696.504100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Na
  • Ti

Synonyms

  • IMA1964-018
  • Zussmaniet

In other languages

German
IMA 1964-018 · Zussmanit
Italian
Zussmanite
Chinese
菱硅钾铁石

Classification

Strunz
10th ed.

9.EG.35

  • 9SilicatesClass
  • 9.EPhyllosilicatesDivision
  • 9.EGDouble nets with 6-membered and larger ringsGroup
  • 9.EG.35ZussmaniteSpecies
Dana
8th ed.

74.01.04.01

  • 74Phyllosilicates Modulated LayersClass
  • 74.01Modulated Layers with joined islandsType
  • 74.01.04— unnamed intermediate level —Group
  • 74.01.04.01ZussmaniteSpecies
CIM

16.16.17

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.16Aluminosilicates of MnGroup
  • 16.16.17ZussmaniteSpecies

Group, growth & confusion

Commonly confused with
2 minerals

Literature, links & citation

Citations
  1. 1964Agrell, S.O. (1964), Deerite, howieite, and zussmanite, three new minerals from the Franciscan of the Laytonville district, Mendocino County, California (title only), American Mineralogist: 49.
  2. 1965Agrell, S.O., M.G. Brown & McKie (1965) Deerite, howieite and zussmanite, three new minerals from the Franciscan of the Laytonville district, Mendocino County, California: American Mineralogist: 50: 278.
  3. 1967Lopes-Vieira, A., Zussman, J. (1967) The crystal structure of the mineral zussmanite. Mineralogical Magazine and Journal of the Mineralogical Society, 36 (278) 292-293 doi:10.1180/minmag.1967.036.278.11 DOI: 10.1180/minmag.1967.036.278.11
  4. 1969Boerner, U. (1969), Deerit, Howieit und Zussmanit, neue seltene Mineralien von einen Steinbruch bei Laytonville in Nord-Kalifornien: Aufschluss: 20: 338-341.
  5. 1969Lopes-Vieira, A., Zussman, J. (1969) Further detail on the crystal structure of zussmanite. Mineralogical Magazine, 37 (285) 49-60 doi:10.1180/minmag.1969.037.285.06 DOI: 10.1180/minmag.1969.037.285.06
