Afghanite

(Na,K)22Ca10(Si24Al24)O96(SO4)6Cl6
IMA status
  • Approved
IMA symbol
Afg
Discovered
1964
IMA approved
1967
Also known as
  • Afghanitt
  • IMA1967-041
  • Natrodavyne

Where it forms, where it's found

Geological setting

Lapis lazuli-bearing skarn

In silicified limestone xenoliths in pumice (Pitigliano quarry, Italy).

Type locality
Ladjuar Medam
  1. Sar-e-Sang
  2. Kuran wa Munjan District
  3. Badakhshan
  4. Afghanistan

36.2100°, 70.8008°

21recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105.5 – 6/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
White · light blue · dark blue

Colourless in thin section

Streak
White
Cleavage
Perfect

(1010)

Fracture
Conchoidal
Density
2.55 g/cm³

Optical

Optical type
Uniaxial (+)
Refractive index
1.523 – 1.529
Surface relief
Moderate
Principal indices
nω 1.523 · nε 1.529
Michel-Lévy diagramhighlighted lineδ = 0.0060
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]60 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation60 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
P3 1c
Cell parameters
a = 12.8013(7) Å · c = 21.4119(18) Å
Morphology

Hexagonal prisms with steep terminations ( scalenohera or rhombohedra?). Also as stout to slender, thin tabular laths and as rounded grains.

Type-locality form

In thin veinlets cutting lazurite crystals.

Comment

Cell data from Ballirano et al. (1996). Previously assumed space group P63mc is incorrect.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen12015.9991919.880
35.47%
19KPotassiumPotassium2239.098860.156
15.89%
14SiSiliconSilicon2428.085674.040
12.45%
13AlAluminiumAluminium2426.982647.568
11.96%
11NaSodiumSodium2222.990505.780
9.34%
20CaCalciumCalcium1040.078400.780
7.41%
17ClChlorineChlorine635.450212.700
3.93%
16SSulfurSulfur632.060192.360
3.55%
Total5413.264100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Afghanitt
  • IMA1967-041
  • Natrodavyne

In other languages

French
Afghanite
German
Afghanit · IMA 1967-041
Spanish
Afghanita
Italian
afghanite
Portuguese
afeganite · IMA1967-041
Chinese
阿钙霞石
Russian
Афганит

Classification

Strunz
10th ed.

9.FB.05

  • 9SilicatesClass
  • 9.FTektosilicates without zeolitic H2ODivision
  • 9.FBTektosilicates with additional anionsGroup
  • 9.FB.05AfghaniteSpecies
Dana
8th ed.

76.02.05.01

  • 76Tectosilicates Al-si FrameworkClass
  • 76.02Al-Si Framework Feldspathoids and related speciesType
  • 76.02.05Cancrinite groupGroup
  • 76.02.05.01AfghaniteSpecies
CIM

17.10.12

  • 17Silicates Containing other AnionsClass
  • 17.10Silicates with sulphate, molybdate or tungstateGroup
  • 17.10.12AfghaniteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1968Bariand, Pierre, Cesbron, Fabien, Giraud, Roger (1968) Une nouvelle espèce minérale : l'afghanite de Sar-e-Sang, Badakhshan, Afghanistan. Comparaison avec les minéraux de groupe de la cancrinite. Bulletin de Minéralogie, 91 (1) 34-42 doi:10.3406/bulmi.1968.6184DOI: 10.3406/bulmi.1968.6184
  2. 1968Fleisher, Michael (1968) New Mineral Names. American Mineralogist, 53 (11-12) 2103-2106
  3. 1979Leoni, L., Mellini, M., Merlino, S., Orlandi, P. (1979) Cancrinite-like minerals: new data and crystal chemical considerations. Rendiconti della Società Italiana di Mineralogia e Petrologia: 35: 713-719.
  4. 1979Hogarth, Donald D. (1979) Afghanite: new occurrences and chemical composition. The Canadian Mineralogist, 17 (1) 47-52
  5. 1979Rinaldi, R., Wenk, H. R. (1979) Stacking variations in cancrinite minerals. Acta Crystallographica Section A: Crystal Physics, Diffraction, Theoretical and General Crystallography, 35 (5). 825-828 doi:10.1107/s0567739479001868DOI: 10.1107/s0567739479001868
Cite this entry
@misc{mineral2026,
  author    = {Mineral Index editorial board},
  title     = {Afghanite — Mineral Index},
  year      = {2026},
  url       = {https://mineralindex.org/minerals/afghanite-41},
  note      = {Accessed 2026-05-11}
}
