Cancrinite

(Na,Ca,◻)8(Al6Si6)O24(CO3,SO4)2 · 2H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Ccn
Discovered
1839

Where it forms, where it's found

Geological setting

Primary mineral in alkalic igneous rocks, alteration product of nepheline.

Type locality
Ilmen Nature Reserve
  1. Chelyabinsk Oblast
  2. Russia
319recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105 – 6/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
grey-green · white · yellow · blue · orange · reddish
Streak
white
Tenacity
brittle
Cleavage
Perfect

Perfect on (1010), poor on (0001)

Fracture
Irregular/Uneven
Density
2.42 g/cm³

Optical

Optical type
Uniaxial (+/-)
Refractive index
1.495 – 1.528
Surface relief
Moderate
Principal indices
nω 1.507 – 1.528 · nε 1.495 – 1.503
Michel-Lévy diagramhighlighted lineδ = 0.0185
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]185 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation185 nm
Order1st order
XPL colour

Crystallography

Crystal system
Hexagonal
Space group
#104
Cell parameters
a = 12.67(9) Å · c = 5.15(4) Å
Z
1
Morphology

Commonly massive, rarely as prismatic crystals.

Twinning

Rare lamellar

Comment

Range of unit-cell parameters: a = 12.58-12.76 Å, c = 5.11-5.20 Å.

Crystal structure

Chemical composition

Impurities
  • Ti
  • Fe
  • Mg
  • K
  • Cl
  • S

In other languages

French
Cancrinite
German
Cancrinit
Spanish
Cancrinita
Italian
Cancrinite
Japanese
カリ霞石
Chinese
鈣霞石 · 钙霞石
Simplified Chinese
钙霞石
Russian
Канкринит
Arabic
كانكرينيت

Classification

Strunz
10th ed.

9.FB.05

  • 9SilicatesClass
  • 9.FTektosilicates without zeolitic H2ODivision
  • 9.FBTektosilicates with additional anionsGroup
  • 9.FB.05CancriniteSpecies
Dana
8th ed.

76.02.05.03

  • 76Tectosilicates Al-si FrameworkClass
  • 76.02Al-Si Framework Feldspathoids and related speciesType
  • 76.02.05Cancrinite groupGroup
  • 76.02.05.03CancriniteSpecies
CIM

17.4.7

  • 17Silicates Containing other AnionsClass
  • 17.4Silicates with carbonatesGroup
  • 17.4.7CancriniteSpecies

Group, growth & confusion

Often grow together
7 minerals

Literature, links & citation

Citations
  1. 1892Dana, Edward Salisbury; Dana, James Dwight (1892) A System of Mineralogy (6th ed.). John Wiley & Sons, Inc.
  2. 1964Edgar, A. D. (1964) Studies on cancrinites; Part 2, Stability fields and cell dimensions of calcium and potassium-rich cancrinites. The Canadian Mineralogist, 8 (1). 53-67
  3. 1965Jarchow, O. (1965) Atomanordnung und Strukturverfeinerung von Cancrinit. Zeitschrift für Kristallographie, 122 (5). 407-422 doi:10.1524/zkri.1965.122.5-6.407 DOI: 10.1524/zkri.1965.122.5-6.407
  4. 1973Foit, F.F., Jr. (1973) Cancrinite with a new superstructure from Bancroft, Ontario. The Canadian Mineralogist: 11: 940-951.
  5. 1982Grundy, H.D., Hassan, I. (1982) The crystal structure of a carbonate-rich cancrinite. The Canadian Mineralogist, 20, 239-251.
