Armalcolite

(Mg,Fe2+)Ti2O5
IMA status
  • Approved
IMA symbol
Arm
Discovered
1970
Also known as
  • Armalcolitt

Where it forms, where it's found

Geological setting

in Ti-rich basalt and microbreccias of lunar samples, formed at low pressures and high temperatures

in salic volcanics; in ultramafic rocks, lamproites and kimberlites; in terrestrial impact craters; in inclusions in carbonaceous chondrites; rarely in granite pegmatites

Type locality
Disko Island
  1. Qeqertalik
  2. Greenland
39recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Grey
Density
4.94 g/cm³

Optical

Optical type
Biaxial
Pleochroism
Visible
Optical colour
Grey to tan
Anisotropism
Strong, pale grey to dark bluish gray
Tropism
Anisotropic
Reflectance R%
(14.1, 15.2) 450 nm, (14.0, 15.0) 470 nm, (13.8, 14.7) 500 nm, (13.7, 14.5) 520 nm, (13.4, 14.4) 546 nm, (13.3, 14.3) 586 nm, (13.2, 14.2) 620 nm, (13.0, 14.1) 640 nm
Reflected-light panel
13.6 %anisotropic · dual curve
Specimen sRGB 136, 95, 52
White reference100 % reflector under same lamp
R₁ R₂
Mode
Anisotropism
Strong, pale grey to dark bluish gray
Reflected colour
Grey to tan

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 9.743 Å · b = 10.023 Å · c = 3.738 Å
Ratio a:b:c
1 : 1.029 : 0.384
Z
2
Type-locality form

subhedral to anhedral grains to 300 µm across

Comment

Space Group: Bbmm

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
22TiTitaniumTitanium247.86795.734
37.41%
8OOxygenOxygen515.99979.995
31.26%
26FeIronIron155.84555.845
21.83%
12MgMagnesiumMagnesium124.30524.305
9.50%
Total255.879100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Armalcolitt

In other languages

French
Armalcolite
German
Armalcolit · Armalcolite
Spanish
Armalcolita
Italian
Armalcolite
Portuguese
armalcolita · Armalcolite
Japanese
アーマルコライト
Chinese
鎂鐵鈦礦 · 阿姆阿尔柯尔矿石
Simplified Chinese
阿姆阿尔柯尔矿石
Traditional Chinese
阿姆阿爾柯爾礦石
Russian
армалколит · армолколит
Arabic
أرمالكوليت · ارمالكوليت

Classification

Strunz
10th ed.

4.CB.15

  • 4OxidesClass
  • 4.CMetal: Oxygen = 2: 3,3: 5, and similarDivision
  • 4.CBWith medium-sized cationsGroup
  • 4.CB.15ArmalcoliteSpecies
Dana
8th ed.

07.07.01.02

  • 07Multiple OxidesClass
  • 07.07AB2X5Type
  • 07.07.01— unnamed intermediate level —Group
  • 07.07.01.02ArmalcoliteSpecies
CIM

7.9.21

  • 7Oxides and HydroxidesClass
  • 7.9Oxides of TiGroup
  • 7.9.21ArmalcoliteSpecies

Group, growth & confusion

In the same group
4 members
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1970Fleischer, Michael (1970) New Mineral Names. American Mineralogist, 55 (11-12) 2135-2139
  2. 1970Anderson, A.T., Bunch, T.E, Cameron, E.N, Haggerty, S.E., Boyd, F.R., Finger, L.W., James, O.B., Keil, K., Prinz, M., Ramdohr, P., El Goresy, A. (1970) Armalcolite, a new mineral from the Apollo 11 samples. Geochimica et Cosmochimica Acta: 34: Supplement 1: 55-63.
  3. 1972Lind, M. D., Housley, R. M. (1972) Crystallization Studies of Lunar Igneous Rocks: Crystal Structure of Synthetic Armalcolite. Science, 175 (4021). 521-523 doi:10.1126/science.175.4021.521DOI: 10.1126/science.175.4021.521
  4. 1973HAGGERTY, S. E. (1973) Ortho and Para-Armalcolite Samples in Apollo 17. Nature Physical Science, 242. 123-125 doi:10.1038/physci242123a0DOI: 10.1038/physci242123a0
  5. 1974Lindsley, D.H., Kesson, S.E., Hartzman, M.J., and Cushman, M.K. (1974) The stability of armalcolite: Experimental studies in the system MgO-Fe-Ti-O. Proceedings of the 5th. Lunar Science Conference, Geochimica et Cosmochimica Acta 61, Supplement 1, 521-534.
Cite this entry
@misc{mineral2026,
  author    = {Mineral Index editorial board},
  title     = {Armalcolite — Mineral Index},
  year      = {2026},
  url       = {https://mineralindex.org/minerals/armalcolite-341},
  note      = {Accessed 2026-05-11}
}
