Armellinoite-(Ce)

Ca4Ce4+(AsO4)4 · H2O
IMA status
  • Approved
IMA symbol
Aml-Ce
IMA approved
2018
Also known as
  • Armellinoiet-(Ce)
  • Armellinoitt-(Ce)
  • IMA2018-094

Where it forms, where it's found

Geological setting

Fe–Mn ore in metaquartzites

Type locality
Montaldo Mine (Montaldo di Mondovì Mine)
  1. Borgata Oberti
  2. Montaldo di Mondovì
  3. Cuneo Province
  4. Piedmont
  5. Italy

44.3189°, 7.8525°

1recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103 – 3.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
pale yellow to brown–yellow · also honey-yellow · canary-yellow · yellow-greenish · yellow-brown
Streak
white
Tenacity
brittle
Cleavage
Imperfect/Fair

|| (110) and (100)

Fracture
Irregular/Uneven
Density
4.29 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.765 – 1.795
Surface relief
High
Principal indices
nω 1.795 · nε 1.765
Pleochroism
Non-pleochroic
UV response
no
Michel-Lévy diagramhighlighted lineδ = 0.0300
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]300 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation300 nm
Order1st order
XPL colour

Crystallography

Crystal system
Tetragonal
Space group
I41/a
Cell parameters
a = 10.749(2) Å · b = 10.749(2) Å · c = 12.030(2) Å
Ratio a:b:c
1 : 1.000 : 1.119
Unit cell volume
1390 ų
Z
4
Type-locality form

pseudo-octahedral crystal embedded in matrix; easily confused with titanite.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
33AsArsenicArsenic474.922299.688
34.28%
8OOxygenOxygen1715.999271.983
31.12%
20CaCalciumCalcium440.078160.312
18.34%
58CeCeriumCerium1140.116140.116
16.03%
1HHydrogenHydrogen21.0082.016
0.23%
Total874.115100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Armellinoiet-(Ce)
  • Armellinoitt-(Ce)
  • IMA2018-094

In other languages

German
Armellinoit-(Ce) · IMA 2018-094

Classification

Strunz
10th ed.

8.CG.25

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.CPhosphates without additional anions, with H2ODivision
  • 8.CGWith large and medium-sized cations, RO4:H2O = 1:1Group
  • 8.CG.25Armellinoite-(Ce)Species

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 2011Kolitsch, U., Ciriotti, M.E., Cadoni, M., Armellino, G., Piccoli, G.C., Ambrino, P., Blass, G., Odicino, G., Ciuffardi, M. (2011) Montaldo di Mondovì Minerali della miniera di manganese e ferro. Micro, 9 (1). 4-21
  2. 2013Kolitsch, U., Ciriotti, M.E., Blaß, G. (2013): Preliminary data on a new natural Ca-Ce4+-arsenate and its crystal structure. Poster, MinPet 2013, September 19-23; abstract in Mitteilungen der Österreichischen Mineralogischen Gesellschaft 159, 75. [http://erdwissenschaften.uni-graz.at/aktuelles/veranstaltungen/minpet2013/downloads/ThirdCircular2013_Final.pdf]
  3. 2018Hålenius, Ulf, Hatert, Frédéric, Pasero, Marco, Mills, Stuart J. (2018) IMA Commission on New Minerals, Nomenclature and Classification (CNMNC) NEWSLETTER 46. European Journal of Mineralogy, 30 (6) 1181-1189 doi:10.1127/ejm/2018/0030-2819DOI: 10.1127/ejm/2018/0030-2819
  4. 2021Cámara, Fernando, Ciriotti, Marco E., Kolitsch, Uwe, Bosi, Ferdinando, Bittarello, Erica, Brizio, Piero, Vignola, Pietro, Blaß, Günter (2021) Armellinoite-(Ce), Ca4Ce4+(AsO4)4⋅H2O, a new mineral species isostructural with pottsite, (Pb3Bi)Bi(VO4)4⋅H2O. Mineralogical Magazine, 85 (6) 901-909 doi:10.1180/mgm.2021.84DOI: 10.1180/mgm.2021.84
  5. 2022(2022) Armellinoite-(Ce). Handbook of Mineralogy. Mineralogical Society of America
