Pottsite

(Pb3Bi)Bi(VO4)4 · H2O
IMA status
  • Approved
IMA symbol
Pot
IMA approved
1988
Also known as
  • IMA1986-045
  • Pottsiet

Where it forms, where it's found

Geological setting

Tungsten mineralization in tactites adjoining a grandiorite intrusion that saw later retrograde metamorphism and fracturing cut by pyrite, chlorite and hematite.

Type locality
Linka Mine
  1. Spencer Hot Springs Mining District
  2. Lander County
  3. Nevada
  4. USA

39.3284°, -116.8368°

5recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Colour
Bright yellow
Streak
Pale yellow
Tenacity
brittle
Cleavage
None Observed
Density
7.0 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
2.3 – 2.4
Surface relief
Very high
Principal indices
nω 2.4 · nε 2.3
Michel-Lévy diagramhighlighted lineδ = 0.1000
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1000 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1000 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Tetragonal
Space group
I41/a
Cell parameters
a = 11.084 Å · c = 12.634 Å
Morphology

Bipyramids or stubby prisms terminated by pyramids. Forms include (101) (dominant), (110), (103), and (211).

Twinning

Twinning not observed.

Type-locality form

Euhedral crystals, 0.5-1 mm in size, forming bipyramids or stubby prisms terminated by pyramids.

Comment

Parameters from the recent refinement (Siidra et al., 2016): a=11.0839, c=12.6516

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead3207.200621.600
40.97%
83BiBismuthBismuth2208.980417.960
27.55%
8OOxygenOxygen1715.999271.983
17.92%
23VVanadiumVanadium450.942203.768
13.43%
1HHydrogenHydrogen21.0082.016
0.13%
Total1517.327100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1986-045
  • Pottsiet

In other languages

German
IMA 1986-045 · Pottsit
Italian
Pottsite

Classification

Strunz
10th ed.

8.CG.25

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.CPhosphates without additional anions, with H2ODivision
  • 8.CGWith large and medium-sized cations, RO4:H2O = 1:1Group
  • 8.CG.25PottsiteSpecies
Dana
8th ed.

40.01.04.01

  • 40Hydrated Normal Phosphates, Arsenates and VanadatesClass
  • 40.01AB(XO4)·xH2OType
  • 40.01.04— unnamed intermediate level —Group
  • 40.01.04.01PottsiteSpecies
CIM

21.3.17

  • 21Vanadates (and vanadates with arsenate or phosphate)Class
  • 21.3Vanadates of Al, rare earths, Pb, V or BiGroup
  • 21.3.17PottsiteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1988Williams, S. A. (1988) Pottsite, a New Vanadate from Lander County, Nevada. Mineralogical Magazine, 52 (366) 389-390 doi:10.1180/minmag.1988.052.366.10DOI: 10.1180/minmag.1988.052.366.10
  2. 1989Jambor, John L., Puziewicz, Jacek (1989) New Mineral Names. American Mineralogist, 74 (3-4) 500-504
  3. 2005(2005) Pottsite. Handbook of Mineralogy. Mineralogical Society of America
  4. 2006Frost, Ray L., Henry, Dermot A., Weier, Matt L., Martens, Wayde (2006) Raman spectroscopy of three polymorphs of BiVO4: clinobisvanite, dreyerite and pucherite, with comparisons to (VO4)3-bearing minerals: namibite, pottsite and schumacherite. Journal of Raman Spectroscopy, 37 (7). 722-732 doi:10.1002/jrs.1499DOI: 10.1002/jrs.1499
  5. 2016Kovrugin, Vadim M.; Siidra, Oleg I.; Zaitsev, Anatoly N.; Spratt, John; Shilovskikh, Vladimir; Agakhanov, Atali A.; Turner, Rick W. (2016) The crystal structure and composition of pottsite, (Pb3xBi4-2x)(VO4)4·H2O, 0.8 < x < 1.0. European Journal of Mineralogy, 28 (1). 137-145 doi:10.1127/ejm/2015/0027-2479DOI: 10.1127/ejm/2015/0027-2479
