Arsenuranospathite

Al(UO2)2(AsO4)2F · 20H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Aush
Discovered
1959
Also known as
  • Arsenuranospathiet
  • Arsenuranospathita
  • Arsenuranospathitt

Where it forms, where it's found

Type locality
Sophia Mine
  1. Böckelsbach valley
  2. Wittichen
  3. Schenkenzell
  4. Rottweil
  5. Freiburg Region
  6. Baden-Württemberg
  7. Germany

48.3333°, 8.3333°

18recorded occurrences
Source · OpenStreetMap

Radioactivity

Physical

Hardness
123456789102/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Colour
Pale yellow

Optical

Optical type
Uniaxial (-)
Refractive index
1.538 – 1.542
Surface relief
Moderate
Principal indices
nω 1.542 · nε 1.538
Michel-Lévy diagramhighlighted lineδ = 0.0040
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]40 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation40 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
#37
Cell parameters
a = 29.9262(7) Å · b = 7.1323(1) Å · c = 7.1864(1) Å
Ratio a:b:c
1 : 0.238 : 0.240
Unit cell volume
1533.9 ų
Z
2
Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen3215.999511.968
41.82%
92UUraniumUranium2238.029476.058
38.89%
33AsArsenicArsenic274.922149.844
12.24%
1HHydrogenHydrogen401.00840.320
3.29%
13AlAluminiumAluminium126.98226.982
2.21%
9FFluorineFluorine118.99818.998
1.55%
Total1224.170100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • P

Synonyms

  • Arsenuranospathiet
  • Arsenuranospathita
  • Arsenuranospathitt

In other languages

German
Arsenuranospathit
Italian
Arsenuranospathite

Classification

Strunz
10th ed.

8.EB.25

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.EUranyl phosphates and arsenatesDivision
  • 8.EBUO2:RO4 = 1:1Group
  • 8.EB.25ArsenuranospathiteSpecies
Dana
8th ed.

40.2a.23.01

  • 40Hydrated Normal Phosphates, Arsenates and VanadatesClass
  • 40.2aAB2(XO4)2·xH2O, containing (UO2)2+Type
  • 40.2a.23— unnamed intermediate level —Group
  • 40.2a.23.01ArsenuranospathiteSpecies
CIM

20.7.14

  • 20Arsenates (also arsenates with phosphate, but without other anions)Class
  • 20.7Arsenates of UGroup
  • 20.7.14ArsenuranospathiteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1978Walenta, Kurt (1978) Uranospathite and arsenuranospathite. Mineralogical Magazine, 42 (321) 117-128 doi:10.1180/minmag.1978.042.321.18 DOI: 10.1180/minmag.1978.042.321.18
  2. 2005(2005) Arsenuranospathite. Handbook of Mineralogy. Mineralogical Society of America
  3. 2009Chukanov, N. V., Möckel, S., Sidorenko, G. A., Zaitsev, V. A. (2009) Arsenuranospathite, Al(UO2)2(AsO4)2F·20H2O: Formula revision and relationships with allied uranyl arsenates and phosphates. Neues Jahrbuch für Mineralogie - Abhandlungen, 185 (3) 305-312 doi:10.1127/0077-7757/2009/0129DOI: 10.1127/0077-7757/2009/0129
  4. 2015Dal Bo, Fabrice, Hatert, Frédéric, Baijot, Maxime, Philippo, Simon (2015) Crystal structure of arsenuranospathite from Rabejac, Lodève, France. European Journal of Mineralogy, 27 (4) 589-597 doi:10.1127/ejm/2015/0027-2461DOI: 10.1127/ejm/2015/0027-2461
  5. 2016Theye, Thomas, Walenta, Kurt, Markl, Gregor (2016) The chemical composition of uranospathite, arsenuranospathite, and associated minerals revisited: the peculiarity of fluorine incorporation in autunite group minerals. Neues Jahrbuch für Mineralogie - Abhandlungen: Journal of Mineralogy and Geoche, 193 (1) 59-68 doi:10.1127/njma/2015/0292DOI: 10.1127/njma/2015/0292
