Uranospathite

(Al,◻)(UO2)2F(PO4)2 · 20H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Ush
Discovered
1915
Also known as
  • Uranospathiet
  • Uranospathita
  • Uranspat

Where it forms, where it's found

Type locality
Wheal Basset
  1. Basset Mines
  2. Carnkie
  3. Carn Brea
  4. Cornwall
  5. England
  6. UK

50.2138°, -5.2372°

18recorded occurrences
Source · OpenStreetMap

Radioactivity

Physical

Hardness
123456789102 – 2.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Yellow · light yellow-green · pale green
Cleavage
Perfect

On (001), perfect; on (100) and (010), good.

Density
2.5 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 69° · 2V calc = 70°
Refractive index
1.492 – 1.521
Surface relief
Moderate
Principal indices
nα 1.492 · nβ 1.51 · nγ 1.521
Pleochroism
Visible

X = Pale yellow Y = Z = Deep yellow

Dispersion
r > v strong
Notes

anomalous

Michel-Lévy diagramhighlighted lineδ = 0.0290
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]290 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation290 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
#37
Cell parameters
a = 30.020(4) Å · b = 7.0084(9) Å · c = 7.0492(9) Å
Ratio a:b:c
1 : 0.233 : 0.235
Unit cell volume
1483.1 ų
Z
2
Morphology

Crystals platy, rectangular, flattened on (001), striated parallel to the elongation [010], and exhibiting (100) and (010), in fanlike groups.

Twinning

On (110), forming cruciform groupings.

Comment

Pseudotetragonal (P42/n, a = 7.00, c = 30.02 A)

Crystal structure

Synonyms

  • Uranospathiet
  • Uranospathita
  • Uranspat

In other languages

German
Uranospathit
Italian
Uranospathite

Classification

Strunz
10th ed.

8.EB.25

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.EUranyl phosphates and arsenatesDivision
  • 8.EBUO2:RO4 = 1:1Group
  • 8.EB.25UranospathiteSpecies
Dana
8th ed.

40.2a.22.01

  • 40Hydrated Normal Phosphates, Arsenates and VanadatesClass
  • 40.2aAB2(XO4)2·xH2O, containing (UO2)2+Type
  • 40.2a.22— unnamed intermediate level —Group
  • 40.2a.22.01UranospathiteSpecies
CIM

19.11.32

  • 19PhosphatesClass
  • 19.11Phosphates of UGroup
  • 19.11.32UranospathiteSpecies

Group, growth & confusion

Often grow together
1 mineral
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1915Hallimond, A. F. (1915) On Bassetite and Uranospathite, new species hitherto classed as Autunite. Mineralogical Magazine and Journal of the Mineralogical Society, 17 (81) 221-236 doi:10.1180/minmag.1915.017.81.11 DOI: 10.1180/minmag.1915.017.81.11
  2. 1951Palache, Charles; Berman, Harry; Frondel, Clifford (1951) The System of Mineralogy (7th ed.) Vol. 2 - Halides, Nitrates, Borates, Carbonates, Sulfates, Phosphates, Arsenates, Tungstates, Molybdates, Etc. John Wiley and Sons.
  3. 1978Walenta, Kurt (1978) Uranospathite and arsenuranospathite. Mineralogical Magazine, 42 (321) 117-128 doi:10.1180/minmag.1978.042.321.18 DOI: 10.1180/minmag.1978.042.321.18
  4. 1979American Mineralogist (1979) 64: 465.
  5. 2005Locock, A. J., Kinman, W. S., Burns, P. C. (2005) The structure and composition of uranospathite, Al1–xx[(UO2)(PO4)]2(H2O)20+3xF1–3x, 0 < x < 0.33, a non-centrosymmetric fluorine-bearing mineral of the autunite group, and of a related synthetic lower hydrate, Al0.670.33[(UO2)(PO4)]2(H2O)15.5. The Canadian Mineralogist, 43 (3) 989-1003 doi:10.2113/gscanmin.43.3.989 DOI: 10.2113/gscanmin.43.3.989
