Athabascaite

Cu5Se4
IMA status
  • Approved
IMA symbol
Atb
Discovered
1949
IMA approved
1969
Also known as
  • Athabascaiet
  • Athabascaitt
  • IMA1969-022

Where it forms, where it's found

Geological setting

As inclusions in and replacements of umangite, as stringers and veinlets in carbonate veins cutting basalt.

In basaltic rocks

Type locality
Martin Lake mine
  1. Beaverlodge Lake area
  2. Saskatchewan
  3. Canada

59.5458°, -108.5528°

21recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Metallic
Transparency
Opaque
Colour
Light grey · bluish-grey to white

May tarnish blue and/or deep yellow.

Density
6.59 g/cm³

Optical

Pleochroism
Weak

Light gray to blue-gray

Anisotropism
Strong, creamy white to dark blue
Tropism
Anisotropic
Reflectance R%
(21.2, 25.1) 400, (19.9, 25.2) 420, (19.6, 25.3) 440, (19.3, 25.4) 460, (19.0, 25.5) 480, (18.6, 25.6) 500, (18.3, 25.6) 520, (17.8, 25.5) 540, (17.4, 25.4) 560, (16.9, 25.1) 580, (16.3, 25.0) 600, (15.5, 24.5) 620, (15.0, 24.2) 640, (14.2, 23.7) 660, (13.4, 23.1) 680, (12.5, 22.4) 700
UV response
Not fluorescent in UV
Reflected-light panel
17.2 %anisotropic · dual curve
Specimen sRGB 147, 108, 62
White reference100 % reflector under same lamp
R₁ R₂
Mode
Anisotropism
Strong, creamy white to dark blue

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 8.227 Å · b = 11.982 Å · c = 6.441 Å
Ratio a:b:c
1 : 1.456 : 0.783
Z
4
Morphology

Commonly laths to 100 microns, sometimes larger

Comment

Point Group: n.d.; Space Group: n.d.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
29CuCopperCopper563.546317.730
50.15%
34SeSeleniumSelenium478.971315.884
49.85%
Total633.614100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • S

Synonyms

  • Athabascaiet
  • Athabascaitt
  • IMA1969-022

In other languages

French
Athabascaïte
German
Athabascait · IMA 1969-022
Italian
Athabascaite

Classification

Strunz
10th ed.

2.BA.25

  • 2Sulfides and SulfosaltsClass
  • 2.BMetal Sulfides, M: S > 1: 1 (mainly 2: 1)Division
  • 2.BAWith Cu, Ag, AuGroup
  • 2.BA.25AthabascaiteSpecies
Dana
8th ed.

02.16.17.01

  • 02SulfidesClass
  • 02.16MiscellaneousType
  • 02.16.17— unnamed intermediate level —Group
  • 02.16.17.01AthabascaiteSpecies
CIM

3.1.13

  • 3Sulphides, Selenides, Tellurides, Arsenides and Bismuthides (except the arsenides, antimonides and bismuthides of Cu, Ag and Au, which are included in Section 1)Class
  • 3.1Sulphides etc. of CuGroup
  • 3.1.13AthabascaiteSpecies

Group, growth & confusion

Often grow together
3 minerals

Literature, links & citation

Citations
  1. 1968Bernardini, G.P., Catani, A. (1968) The Cu-Se system. Mineralium Deposita, 3 (4). 375-380 doi:10.1007/bf00207529DOI: 10.1007/bf00207529
  2. 1969HARRIS, D.C., CABRI, L.J. & KAIMAN, S. (1969): A new copper selenide from Martin Lake, Saskatchewan. Canadian Mineralogist 10, 135 136 (abstr.).
  3. 1970Harris, D. C, Cabri, L. J., Kaiman, S. (1970) Athabascaite, a new copper selenide mineral from Martin Lake, Saskatchewan. The Canadian Mineralogist, 10 (2) 207-215
  4. 1971Fleischer, Michael (1971) New Mineral Names. American Mineralogist, 56 (3-4) 631-640
  5. 2005(2005) Athabascaite. Handbook of Mineralogy. Mineralogical Society of America
