Petrovicite

Cu3HgPbBiSe5
IMA status
  • Approved
IMA symbol
Pvc
Discovered
1976
Also known as
  • IMA1975-010
  • Petroviciet

Where it forms, where it's found

Geological setting

Hydrothermal dolomite-calcite veins.

Type locality
Petrovice
  1. Nové Město na Moravě
  2. Žďár nad Sázavou District
  3. Vysočina Region
  4. Czech Republic

49.5459°, 16.0626°

4recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Cream
Cleavage
Poor/Indistinct

Imperfect, parallel to flattening of crystals.

Density
7.707 g/cm³

Optical

Optical colour
Cream
Anisotropism
Weak; dark green and violet
Tropism
Anisotropic
Reflectance R%
(44.0,44.4) 400, (44.1,44.8) 420, (44.2,45.2) 440, (44.3,45.4) 460, (44.4,45.7) 480, (44.7,46.1) 500, (45.1,46.3) 520, (45.2,46.5) 540, (45.2,46.4) 560, (45.1,46.2) 580, (45.1,46.0) 600, (45.0,45.9) 620, (44.9,45.8) 640, (44.9,45.7) 660, (44.8,45.6) 680, (44.8,45.5) 700
Reflected-light panel
44.7 %anisotropic · dual curve
Specimen sRGB 237, 166, 91
White reference100 % reflector under same lamp
R₁ R₂
Mode
Anisotropism
Weak; dark green and violet
Reflected colour
Cream

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 16.176(5) Å · b = 14.684(5) Å · c = 4.331(3) Å
Ratio a:b:c
1 : 0.908 : 0.268
Z
4
Morphology

Crystals are tabular, to a few tenths of one mm.

Type-locality form

Tabular crystals up to a few tenths of a millimeter. Almost completely replaced by umangite and eskebornite.

Comment

Point Group: 2/m 2/m 2/m or mm2.; Space Group: P nam or P na21.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
34SeSeleniumSelenium578.971394.855
32.84%
83BiBismuthBismuth1208.980208.980
17.38%
82PbLeadLead1207.200207.200
17.23%
80HgMercuryMercury1200.592200.592
16.69%
29CuCopperCopper363.546190.638
15.86%
Total1202.265100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1975-010
  • Petroviciet

In other languages

German
IMA 1975-010 · Petrovicit
Italian
Petrovicite

Classification

Strunz
10th ed.

2.LB.40

  • 2Sulfides and SulfosaltsClass
  • 2.LUnclassified SulfosaltsDivision
  • 2.LBWith essential PbGroup
  • 2.LB.40PetroviciteSpecies
Dana
8th ed.

03.01.09.01

  • 03SulfosaltsClass
  • 03.01ø > 4Type
  • 03.01.09— unnamed intermediate level —Group
  • 03.01.09.01PetroviciteSpecies
CIM

5.7.18

  • 5Sulphosalts - Sulpharsenites and Sulphobismuthites (those containing Sn, Ge,or V are in Section 6)Class
  • 5.7Sulpharsenites etc. of Pb and other metalsGroup
  • 5.7.18PetroviciteSpecies

Group, growth & confusion

Often grow together
11 minerals

Literature, links & citation

Citations
  1. 1976Johan, Zdenek, Kvacek, Milan, Picot, Paul (1976) La petrovicite, Cu3HgPbBiSe5, un nouveau minéral. Bulletin de Minéralogie, 99 (5) 310-313 doi:10.3406/bulmi.1976.7086 DOI: 10.3406/bulmi.1976.7086
  2. 1977Fleischer, Michael, Cabri, Louis J., Nickel, Ernest H., Pabst, Adolf (1977) New Mineral Names. American Mineralogist, 62 (5-6) 593-600
  3. 1991Dymkov, Yu.M., Ryzhov, B.I., Begizov, V.I., Dubakina, L.S., Zav'yalov, E.N., Ryabeva, V.G., Tsvetkova, M.V. (1991) Mgriite, bismuth petrovicite and associated selenides from carbonate veins of the Erzgebirge. Novye Dannye o Mineralakh: 37: 81-101 (in Russian).
  4. 2005(2005) Petrovicite. Handbook of Mineralogy. Mineralogical Society of America
