Banalsite

Na2BaAl4Si4O16
IMA status
  • Approved
  • Grandfathered
IMA symbol
Bns
Discovered
1944
Also known as
  • Banalsiet

Where it forms, where it's found

Type locality
Benallt Mine
  1. Rhiw
  2. Aberdaron
  3. Gwynedd
  4. Wales
  5. UK

52.8207°, -4.6390°

23recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
White
Streak
White
Cleavage
Distinct/Good

(110) and (001).

Density
3.05 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 41° · 2V calc = 52°
Refractive index
1.5695 – 1.5775
Surface relief
Moderate
Principal indices
nα 1.5695 · nβ 1.5710 · nγ 1.5775
Dispersion
r > v
Michel-Lévy diagramhighlighted lineδ = 0.0080
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]80 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation80 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
#25
Cell parameters
a = 8.5400(7) Å · b = 10.0127(5) Å · c = 16.7897(14) Å
Ratio a:b:c
1 : 1.172 : 1.966
Twinning

none

Comment

Benallt

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1615.999255.984
38.81%
56BaBariumBarium1137.327137.327
20.82%
14SiSiliconSilicon428.085112.340
17.03%
13AlAluminiumAluminium426.982107.928
16.37%
11NaSodiumSodium222.99045.980
6.97%
Total659.559100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Mn
  • Mg
  • Ca
  • K

Synonyms

  • Banalsiet

In other languages

German
Banalsit
Spanish
Banalsita
Italian
Banalsite
Chinese
钠钡长石

Classification

Strunz
10th ed.

9.FA.60

  • 9SilicatesClass
  • 9.FTektosilicates without zeolitic H2ODivision
  • 9.FATektosilicates without additional non-tetrahedral anionsGroup
  • 9.FA.60BanalsiteSpecies
Dana
8th ed.

76.01.06.01

  • 76Tectosilicates Al-si FrameworkClass
  • 76.01Al-Si Framework with Al-Si frameworksType
  • 76.01.06Banalsite groupGroup
  • 76.01.06.01BanalsiteSpecies
CIM

16.12.8

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.12Aluminosilicates of Sr, Ba and ZnGroup
  • 16.12.8BanalsiteSpecies

Group, growth & confusion

Often grow together
2 minerals

Literature, links & citation

Citations
  1. Mineralogical Journal: 7: 262-281.
  2. 1944Smith, W. Campbell; Bannister, F. A.; Hey, Max H. (1944) Banalsite, a new barium-felspar from Wales. Mineralogical Magazine and Journal of the Mineralogical Society, 27 (186). 33-47 doi:10.1180/minmag.1944.027.186.01 DOI: 10.1180/minmag.1944.027.186.01
  3. 1945Fleischer, M. (1945) New mineral names. American Mineralogist, 30 (1-2). 85-86
  4. 1969Welin, E. (1969) Notes on the mineralogy of Sweden 6. X-ray powder data for minerals from Långban and the related mineral deposits of Central Sweden. Arkiv för Mineralogi och Geologi, 4 (6, nr 30). 499-541
  5. 2006Liferovich, R. P., Locock, A. J., Mitchell, R. H., Shpachenko, A. K. (2006) The crystal structure of stronalsite and a redetermination of the structure of banalsite. The Canadian Mineralogist, 44 (2) 533-546 doi:10.2113/gscanmin.44.2.533 DOI: 10.2113/gscanmin.44.2.533
