Barytocalcite

BaCa(CO3)2
IMA status
  • Approved
  • Grandfathered
IMA symbol
Bcal
Discovered
1824
Also known as
  • Barytocalciet
  • Barytocalcita

Where it forms, where it's found

Geological setting

Veins in limestone.

Type locality
Blagill Mine
  1. Alston Moor
  2. Eden
  3. Cumbria
  4. England
  5. UK

54.8189°, -2.4031°

87recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous · Resinous
Transparency
Transparent · Translucent
Colour
Colourless · white · greyish · greenish · light yellow · pink · pale brown
Streak
White
Tenacity
brittle
Fracture
Irregular/Uneven · Conchoidal
Density
3.66 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 15° · 2V calc = 10°
Refractive index
1.525 – 1.686
Surface relief
Moderate
Principal indices
nα 1.525 · nβ 1.684 · nγ 1.686
Dispersion
relatively weak
UV response
Dull yellow (LW & SW UV).
Michel-Lévy diagramhighlighted lineδ = 0.1610
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1610 nm3rd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1610 nm
Order3rd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#15
Cell parameters
a = 8.092(1) Å · b = 5.2344(6) Å · c = 6.544(1) Å
Cell angles
β = 106.05(1) °
Ratio a:b:c
1 : 0.647 : 0.809
Morphology

Crystals normally short to long prismatic [101], also short prismatic [001] or equant. (100) striated [001]; and (111), (252), (131) striated [101]. Massive.

Epitaxy

Witherite xls in parallel growth on Barytocalcite from Blagill. Baryte on barytocalcite, with baryte (001)[010] parallel to barytocalcite (001)[010]. Calcite on barytocalcite, with calcite (101_1), (1_101), and (01_11) approximately parallel to barytocalcite (101), (1_11), and (1_1_1).

Comment

Cell from Dickens & Bowen (1971). Older cell: 8.13, 5.22, 6.54 Å, 106°.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
56BaBariumBarium1137.327137.327
46.17%
8OOxygenOxygen615.99995.994
32.28%
20CaCalciumCalcium140.07840.078
13.47%
6CCarbonCarbon212.01124.022
8.08%
Total297.421100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Barytocalciet
  • Barytocalcita

In other languages

German
Barytocalcit
Spanish
Baritocalcita
Italian
Baritocalcite
Russian
Баритокальцит

Classification

Strunz
10th ed.

5.AB.45

  • 5CarbonatesClass
  • 5.ACarbonates without additional anions, without H2ODivision
  • 5.ABAlkali-earth (and other M2+) carbonatesGroup
  • 5.AB.45BarytocalciteSpecies
Dana
8th ed.

14.02.06.01

  • 14Anhydrous Normal CarbonatesClass
  • 14.02AB(XO3)2Type
  • 14.02.06— unnamed intermediate level —Group
  • 14.02.06.01BarytocalciteSpecies
CIM

11.5.6

  • 11CarbonatesClass
  • 11.5Carbonates of Sr and BaGroup
  • 11.5.6BarytocalciteSpecies

Group, growth & confusion

Commonly confused with
2 minerals

Literature, links & citation

Citations
  1. 1824Brooke, H.J., Children, J.G. (1824) On baryto-calcite. The Annals of Philosophy, London: 8: 114-116.
  2. 1835Johnston, J.F.W. (1835) On the dimorphism of Baryto-calcite. Philosophical Magazine and Journal of Science: 6: 1-4.
  3. 1868Dana, James D., Brush, George Jarvis (1868) A System of Mineralogy (5th ed.). p.882
  4. 1874Des Cloizeaux, A. (1874) Manuel de minéralogie. 2 volumes and Atlas, Paris. volume 2: 80.
  5. 1878Sjögren (1878) Geologiska Föeningens I Stockholm. Förhandlinger, Stockholm: 3: 289.
