Batisite

Na2BaTi2O2(Si2O6)2
IMA status
  • Approved
IMA symbol
Bat
Discovered
1959
Also known as
  • Bananatisite
  • Batisiet

Where it forms, where it's found

Geological setting

In nepheline syenite pegmatite with interstitial crystals of microcline; rarely with miaroles.

Type locality
Inagli chrome diopside deposit
  1. Inagli Massif
  2. Aldan
  3. Sakha
  4. Russia

58.5367°, 124.9140°

11recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105.5 – 6/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Dark brown
Streak
Rose brown
Tenacity
brittle
Cleavage
Imperfect/Fair

Fair on (100), (010), and (001).

Density
3.432 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 7 – 40° · 2V calc = 34°
Refractive index
1.727 – 1.789
Surface relief
High
Principal indices
nα 1.727 · nβ 1.732 · nγ 1.789
Pleochroism
Visible

X = colorless; Y = yellowish brown; Z = reddish brown.

Dispersion
strong
Extinction
Z = c; Y = b; X = a.
Notes

Elongation positive.

Michel-Lévy diagramhighlighted lineδ = 0.0620
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]620 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation620 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
Imma
Cell parameters
a = 8.0921(5) Å · b = 10.4751(7) Å · c = 13.9054(9) Å
Ratio a:b:c
1 : 1.294 : 1.718
Z
4
Morphology

As complex elongated crystals, to 10 cm. Forms include (010), (001), (110), (031), (150), (011), and (310).

Parting
(110)
Comment

Cell parameters from Zolotarev et al. (2017).

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1415.999223.986
36.40%
56BaBariumBarium1137.327137.327
22.32%
14SiSiliconSilicon428.085112.340
18.25%
22TiTitaniumTitanium247.86795.734
15.56%
11NaSodiumSodium222.99045.980
7.47%
Total615.367100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Zr
  • Al
  • Fe
  • Nb
  • Mn
  • Mg
  • Ca
  • Sr

Synonyms

  • Bananatisite
  • Batisiet

In other languages

German
Batisit
Italian
Batisite
Chinese
硅钡钛石

Classification

Strunz
10th ed.

9.DH.20

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DHInosilicates with 4-periodic single chains, Si4O12Group
  • 9.DH.20BatisiteSpecies
Dana
8th ed.

65.03.04.01

  • 65Inosilicates Single-width, Unbranched Chains, (w=1)Class
  • 65.03Single-Width Unbranched Chains, W=1 with chains P=4Type
  • 65.03.04Batisite groupGroup
  • 65.03.04.01BatisiteSpecies
CIM

14.9.10

  • 14Silicates not Containing AluminumClass
  • 14.9Silicates of TiGroup
  • 14.9.10BatisiteSpecies

Group, growth & confusion

In the same group
2 members
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. Doklady Akademii Nauk SSSR, Earth Science Sections: 146: 142-143, 805-808.
  2. 1959Kravchenko, S.M., Vlasova, E.V. (1959) Rare-metal mineralization associated with nepheline syenites of the alkalic province of Central Aldan. Doklady Akademii Nauk SSSR, 128(5), 1046-1049. (in Russian)
  3. 1960Fleischer, M. (1960) New mineral names. American Mineralogist, 45 (7-8). 908-910
  4. 1960Fleischer, M. (1960) New mineral names. American Mineralogist, 45 (11-12). 1313-1317
  5. 1960Kravchenko, S.M., Vlasova, E.V., Pinevich, N.G. (1960) Batisite — a new mineral. Doklady Akademii Nauk SSSR, 133, 657-660.
