Baumhauerite

Pb12As16S36
IMA status
  • Approved
  • Grandfathered
IMA symbol
Bha
Discovered
1902
Also known as
  • Baumhauerite-I
  • IMA1988-061

Where it forms, where it's found

Geological setting

Dolomite

Type locality
Lengenbach Quarry
  1. Fäld
  2. Binn
  3. Goms
  4. Valais
  5. Switzerland

46.3653°, 8.2205°

18recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Metallic
Transparency
Opaque
Colour
Lead-grey · steel-grey · iridescent at times
Streak
Chocolate-brown
Tenacity
brittle
Cleavage
Perfect

On (100) perfect.

Fracture
Conchoidal
Density
5.33 g/cm³

Optical

Optical colour
White
Anisotropism
Strong, in dark brown, pale brown, pale brownish grey, green, violet, blue-green or yellow
Internal reflections
Deep red
Tropism
Anisotropic
Reflectance R%
(38.0, 42.1) 400, (37.6, 41.9) 420, (37.2, 41.6) 440, (36.8, 41.2) 460, (36.4, 40.7) 480, (36.0, 40.4) 500, (35.5, 39.8) 520, (35.1, 39.2) 540, (34.6, 38.6) 560, (34.2, 37.9) 580, (33.7, 37.2) 600, (33.2, 36.5) 620, (32.5, 35.7) 640, (31.8, 34.9) 660, (31.1, 34.2) 680, (30.5, 33.5) 700
UV response
Not fluorescent in UV
Reflected-light panel
34.6 %anisotropic · dual curve
Specimen sRGB 206, 148, 85
White reference100 % reflector under same lamp
R₁ R₂
Mode
Anisotropism
Strong, in dark brown, pale brown, pale brownish grey, green, violet, blue-green or yellow
Reflected colour
White
Internal reflections
Deep red

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 22.74 Å · b = 8.33 Å · c = 7.89 Å
Cell angles
α = 90.35 ° · β = 97 ° · γ = 90.42 °
Ratio a:b:c
1 : 0.366 : 0.347
Z
4
Morphology

Short prismatic [010]; tabular (100); striated on (100) parallel to [010] and on (010) parallel to [001]. Some crystals considerably rounded, as by etching.

Twinning

On (100), polysynthetic, with visible twin lamellae.

Type-locality form

Isolated crystals, closely resembling dufrenoysite and jordanite.

Comment

Pseudomonoclinic. Also a = 22.905, b = 8.329, c = 7.957 (ICDD 12-281)

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead12207.2002486.400
51.38%
33AsArsenicArsenic1674.9221198.752
24.77%
16SSulfurSulfur3632.0601154.160
23.85%
Total4839.312100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Sb

Synonyms

  • Baumhauerite-I
  • IMA1988-061

In other languages

German
Baumhauerit
Spanish
Baumhauerita
Italian
Baumhauerite
Chinese
褐硫砷铅矿

Classification

Strunz
10th ed.

2.HC.05b

  • 2Sulfides and SulfosaltsClass
  • 2.HSulfosalts of SnS archetypeDivision
  • 2.HCWith only PbGroup
  • 2.HC.05bBaumhaueriteSpecies
Dana
8th ed.

03.06.13.01

  • 03SulfosaltsClass
  • 03.062 < ø < 2.49Type
  • 03.06.13— unnamed intermediate level —Group
  • 03.06.13.01BaumhaueriteSpecies
CIM

5.6.4

  • 5Sulphosalts - Sulpharsenites and Sulphobismuthites (those containing Sn, Ge,or V are in Section 6)Class
  • 5.6Sulpharsenites etc. of Pb aloneGroup
  • 5.6.4BaumhaueriteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1902Solly, R. H., Jackson, H. (1902) Sulpharsenites of Lead from the Binnenthal. Part III.—Baumhauerite, a new mineral; and Dufrenoysite. Mineralogical Magazine and Journal of the Mineralogical Society, 13 (60) 151-171 doi:10.1180/minmag.1902.13.60.04 DOI: 10.1180/minmag.1902.13.60.04
  2. 1903Solly R.H. (1903), Z. Krystallogr.: 37: 321.
  3. 1903Solly, R. H. (1903) Sulpharsenites of lead from the Binnenthal. Part IV.—Seligmannite : with a supplementary note on Baumhauerite. Mineralogical Magazine and Journal of the Mineralogical Society, 13 (62) 336-341 doi:10.1180/minmag.1903.013.62.07 DOI: 10.1180/minmag.1903.013.62.07
  4. 1938Palache, Charles (1938) Crystallographic studies of the sulphosalts: baumhauerite, meneghinite, jordanite, diaphorite, freieslebenite. American Mineralogist, 23 (11) 821-836
  5. 1944Palache, Charles, Berman, Harry, Frondel, Clifford (1944) The System of Mineralogy (7th ed.) Vol. 1 - Elements, Sulfides, Sulfosalts, Oxides. John Wiley and Sons, New York.
