Bavenite

Ca4Be2+xAl2-xSi9O26-x(OH)2+x (x = 0 to 1)
IMA status
  • Approved
  • Grandfathered
IMA symbol
Bvn
Discovered
1901
Also known as
  • Pilinite

Where it forms, where it's found

Geological setting

In miarolitic cavities in granite.

Type locality
Seula mine
  1. Mount Camoscio
  2. Oltrefiume
  3. Baveno
  4. Verbano-Cusio-Ossola Province
  5. Piedmont
  6. Italy

45.9167°, 8.4836°

258recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789105.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
White
Streak
White
Cleavage
Perfect

Perfect on (001), fair on (100)

Density
2.71 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 22 – 60° · 2V calc = 54°
Refractive index
1.578 – 1.593
Surface relief
Moderate
Principal indices
nα 1.578 – 1.586 · nβ 1.579 – 1.586 · nγ 1.583 – 1.593
Dispersion
r < v moderate
Extinction
X = c; Y = b; Z = a
Michel-Lévy diagramhighlighted lineδ = 0.0060
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]60 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation60 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 19.39(2) Å · b = 23.19(2) Å · c = 5.005(9) Å
Ratio a:b:c
1 : 1.196 : 0.258
Z
4
Morphology

Type material: (100) (large), (110), (210), (101), (103).

Twinning

On (100)

Type-locality form

Tufts, with a fibrous radiating structure, or thin prisms.

Comment

Space group Am2a (non-standard setting).

Crystal structure

Synonyms

  • Pilinite

In other languages

French
Bavénite
German
Bavenit
Spanish
Bavenita
Italian
bavenite
Portuguese
Bavenite
Russian
Бавенит

Classification

Strunz
10th ed.

9.DF.25

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DFInosilicates with 2-periodic multiple chainsGroup
  • 9.DF.25BaveniteSpecies
Dana
8th ed.

70.05.03.01

  • 70Inosilicates Column or Tube StructuresClass
  • 70.05Column or Tube Structures with chains linked by BeType
  • 70.05.03— unnamed intermediate level —Group
  • 70.05.03.01BaveniteSpecies
CIM

16.6.3

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.6Aluminosilicates of BeGroup
  • 16.6.3BaveniteSpecies

Group, growth & confusion

Often grow together
1 mineral
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1876von Lasaulx, A. (1876) XII. Pilinit, ein Neues Mineral [XII. Pilinite, a New Mineral], in Mineralogisch-krystallographische Notizen. Erste Folge. Neues Jahrbuch für Mineralogie, Geognosie, Geologie und Petrefaktenkunde, 1876. 358-363
  2. 1901Artini, E. (1901) Di una nuova specie minerale trovata nel granito di Baveno. Atti della Reale Accademia dei Lincei: 10: 139-145.
  3. 1932Schaller, Waldemar T., Fairchild, John G. (1932) Bavenite, a beryllium mineral, pseudomorphous after beryl, from California. American Mineralogist, 17 (9) 409-422
  4. 1933Ksanda, C. J., Merwin, H. E. (1933) Bavenite: Symmetry, unit cell. American Mineralogist, 18 (8) 341-344
  5. 1940Claringbull, G. F. (1940) Occurrences of bavenite in Switzerland. Mineralogical Magazine and Journal of the Mineralogical Society, 25 (168) 495-497 doi:10.1180/minmag.1940.025.168.04 DOI: 10.1180/minmag.1940.025.168.04
