Borcarite

Ca4MgB4O6(CO3)2(OH)6
IMA status
  • Approved
IMA symbol
Bcr
Discovered
1965
Also known as
  • Borcariet

Where it forms, where it's found

Geological setting

Occurs in kotoite marbles, formed in dolomites near a contact with granodiorite.

Type locality
Snezhnoe B ore occurrence
  1. Izvestkovyi Stream
  2. Titovskoe B deposit
  3. Tas-Khayakhtakh Range
  4. Dogdo River Basin
  5. Polar Yakutia
  6. Sakha
  7. Russia

67.6000°, 138.7000°

7recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Greenish-blue to bluish green · nearly colorless · colorless in section
Cleavage
Perfect

Perfect on (100) and (110) and in several directions {hkl} and {hOl} with angles β 50-70°. The cleavage plane (100) is always smooth; the cleavage plane (110) is very often striated parallel to c.

Density
2.77 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 30° · 2V calc = 32°
Refractive index
1.59 – 1.657
Surface relief
Moderate
Principal indices
nα 1.59 · nβ 1.651 · nγ 1.657
Dispersion
r < v distinct
Notes

Z = b; Y ∧ c = 28(4)°

Michel-Lévy diagramhighlighted lineδ = 0.0670
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]670 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation670 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 17.840(4) Å · b = 8.380(2) Å · c = 4.445(1) Å
Cell angles
β = 102.04(3) °
Ratio a:b:c
1 : 0.470 : 0.249
Z
2
Type-locality form

Dense masses up to 0.5 m in diameter and as veins.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1815.999287.982
52.75%
20CaCalciumCalcium440.078160.312
29.37%
5BBoronBoron410.81043.240
7.92%
12MgMagnesiumMagnesium124.30524.305
4.45%
6CCarbonCarbon212.01124.022
4.40%
1HHydrogenHydrogen61.0086.048
1.11%
Total545.909100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Borcariet

In other languages

German
Borcarit
Italian
Borcarite
Japanese
硼灰石

Classification

Strunz
10th ed.

6.DA.40

  • 6BoratesClass
  • 6.DTetraboratesDivision
  • 6.DANeso-tetraboratesGroup
  • 6.DA.40BorcariteSpecies
Dana
8th ed.

27.01.03.01

  • 27Compound BoratesClass
  • 27.01MiscellaneousType
  • 27.01.03— unnamed intermediate level —Group
  • 27.01.03.01BorcariteSpecies
CIM

10.4.3

  • 10Borates with other anionsClass
  • 10.4Borates with carbonateGroup
  • 10.4.3BorcariteSpecies

Group, growth & confusion

Often grow together
1 mineral

Literature, links & citation

Citations
  1. 1965Fleischer, Michael (1965) New Mineral Names. American Mineralogist, 50 (11-12) 2096-2111
  2. 1965Pertzev, N.N., Ostravskaya, I.V., Nikitina, I.B. (1965) The new mineral borcarite. Zapiski Vsesoyuznogo Mineralogicheskogo Obshchestva: 94: 180-186.
  3. 1975Yamnova, N.A., Simonov, M.A., Kazanskaya, E.V., Belov, N.V. (1975) Refinement of the crystal structure of the Ca, Mg-carbonatoborate borcarite Ca4Mg/B4O6(OH)6/(CO3)2. Soviet Physics - Doklady: 20: 799-801.
  4. 1978Malinko, S.V. (1978) Borcarite from Solongo, its parageneses, composition and properties. Trudy Mineralogicheskogo Muzeya, Akademiya Nauk SSSR: 26: 94-104.
  5. 1995Burns, P. C., Hawthorne, F. C. (1995) Hydrogen bonding in borcarite, an unusual borate-carbonate mineral. Mineralogical Magazine, 59 (395) 297-304 doi:10.1180/minmag.1995.059.395.13 DOI: 10.1180/minmag.1995.059.395.13
