Cahnite

Ca2B(AsO4)(OH)4
IMA status
  • Approved
  • Grandfathered
IMA symbol
Cah
Discovered
1921
Also known as
  • Cahniet
  • Calcium Edingtonite

Where it forms, where it's found

Geological setting

Cavities in manganaxinite veinlets traversing Precambrian metamorphosed Zn-Mn-Fe orebody.

cavities in boron-bearing and arsenate-bearing vugs in basalt, boron-bearing and arsenate-bearing hydrothermal veins

Type locality
Franklin Mine
  1. Franklin
  2. Sussex County
  3. New Jersey
  4. USA

41.1158°, -74.5875°

14recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Colorless to white · golden brown

Colourless in transmitted light.

Streak
White
Tenacity
brittle
Cleavage
Perfect

On (110)

Fracture
Irregular/Uneven · Sub-Conchoidal
Density
3.156 g/cm³

Optical

Optical type
Uniaxial (+)
Refractive index
1.655 – 1.663
Surface relief
High
Principal indices
nω 1.655 – 1.662 · nε 1.656 – 1.663
Birefringence
0.001
Pleochroism
Non-pleochroic
Dispersion
Strong; exhibits anomalous interference colors.
UV response
Fluoresces moderate creamy white in SW UV (Franklin).
Notes

Exhibits abnormal interference colours that make the mineral easily recognizable under the microscope.

Michel-Lévy diagramhighlighted lineδ = 0.0010
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]10 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation10 nm
Order1st order
XPL colour

Crystallography

Crystal system
Tetragonal
Space group
#128
Cell parameters
a = 7.09 Å · c = 6.19 Å
Z
2
Morphology

Single untwinned crystals rare, pseudo-tetrahedral habit.

Twinning

Almost universal on (110), with the individuals interpenetrating symmetrically. When the sphenoid faces are well-developed, the twins have a characteristic cruciform appearance.

Type-locality form

Tiny white glassy crystals, characteristically twinned with generally etched crystal faces.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen815.999127.992
42.96%
20CaCalciumCalcium240.07880.156
26.91%
33AsArsenicArsenic174.92274.922
25.15%
5BBoronBoron110.81010.810
3.63%
1HHydrogenHydrogen41.0084.032
1.35%
Total297.912100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Cahniet
  • Calcium Edingtonite

In other languages

French
Cahnite
German
Cahnit
Spanish
Cahnita
Italian
Cahnite
Chinese
水砷硼鈣石 · 砷硼钙石
Arabic
كاهنيت

Classification

Strunz
10th ed.

6.AC.70

  • 6BoratesClass
  • 6.AMonoboratesDivision
  • 6.ACB(O,OH)4, without and with additional anions; 1(T), 1(T)+OH, etcGroup
  • 6.AC.70CahniteSpecies
Dana
8th ed.

43.04.04.01

  • 43Compound Phosphates, Etc.Class
  • 43.04Anhydrous Compound Phosphates, etc·, Containing Hydroxyl or HalogenType
  • 43.04.04— unnamed intermediate level —Group
  • 43.04.04.01CahniteSpecies
CIM

10.2.2

  • 10Borates with other anionsClass
  • 10.2Borates with phosphate or arsenateGroup
  • 10.2.2CahniteSpecies

Group, growth & confusion

Often grow together
2 minerals

Literature, links & citation

Citations
  1. 1927Palache, Charles, Bauer, L. H. (1927) Cahnite, a new boro-arsenate of calcium from Franklin, New Jersey. American Mineralogist, 12 (4) 149-153
  2. 1941Palache, Charles (1941) Crystallographic notes: cahnite, stolzite, zincite, ultrabasite. American Mineralogist, 26 (7) 429-436
  3. 1951Palache, Charles; Berman, Harry; Frondel, Clifford (1951) The System of Mineralogy (7th ed.) Vol. 2 - Halides, Nitrates, Borates, Carbonates, Sulfates, Phosphates, Arsenates, Tungstates, Molybdates, Etc. John Wiley and Sons.
  4. 1960Embrey, P. G. (1960) Cahnite from Capo di Bove, Rome. Mineralogical Magazine and Journal of the Mineralogical Society, 32 (251) 666-668 doi:10.1180/minmag.1960.032.251.10 DOI: 10.1180/minmag.1960.032.251.10
  5. 1961Prewitt, Charles T., Buerger, M. J. (1961) The crystal structure of cahnite, Ca2BAsO4(OH)4. American Mineralogist, 46 (9-10 ) 1077-1085
